Order Vibration Analysis of High-Speed Spindle System

Abstract:

Before the working speed of high-speed spindle system reaches the critical speed, violent vibration which directly affects the quality of the work piece has been already discovered. To precisely study the speed at which violent vibration happens and the modes of vibration, this paper provided an order vibration approach through studying the model analysis and order of spindle system. The nature frequencies of model analysis were verified and the order of spindle system was confirmed by speed ascend experiment. The result shows that the violent vibration is caused by the manufacturing error of outer ring race of bearing and the mode of vibration mainly located on the grinding wheel which greatly affects the accuracy of spindle system. It is useful for optimizing the structure and operation procedure of high-speed spindle system.

• Periodical: Advanced Materials Research (Volumes 712-715)
• Pages: 1653-1658
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.712-715.1653
• Online since: June 2013
• Authors: Zhou Ping Wu, Bei Zhi Li, Jian Guo Yang
• Keywords: High-Speed Spindle, Model Analysis, Order Analysis, Violent Vibration

References

[1] Fan Sabirov, D. Suslov, Sergey Savinov, Diagnostics of spindle unit, model design and analysis, The International Journal of Advanced Manufacturing Technology. DOI10.1007 (2012) s00170-011-3848-7

DOI: 10.1007/s00170-011-3848-7

[2] Hongrui Cao, BingLi,Zhengjia He, Chatter stability of milling with speed-varying dynamics of spindles, International Journal of Machine Tools & Manufacture. 52 (2012) 50–58

DOI: 10.1016/j.ijmachtools.2011.09.004

[3] E. Abele, Y. Altintas, C. Brecher, Machine tool spindle units, CIRP Annals - Manufacturing Technology. 59 (2010) 781–802

DOI: 10.1016/j.cirp.2010.05.002

[4] R.L. Ruhl, J.F. Booker, A finite element model for distributed parameter turbo rotor systems, ASME Journal of Engineering for Industry. Feb (1972)128–139

[5] Yuzhong Cao, Yusuf Altintas, A General Method for the Modeling of Spindle-Bearing Systems, Journal of Mechanical Design. Vol. NOVEMBER (2004) 126-134

[6] ShuyunJiang, ShufeiZheng, 2010,A modeling approach for analysis and improvement of spindle-drawbar-bearing assembly dynamics, International Journal of Machine Tools & Manufacture, 50 /131–142

DOI: 10.1016/j.ijmachtools.2009.08.010

[7] Yuzhong Cao, Y. Altintas, Modeling of spindle-bearing and machine tool systems for virtual simulation of milling operations, International Journal of Machine Tools & Manufacture. 47 (2007) 1342–1350

DOI: 10.1016/j.ijmachtools.2006.08.006

[8] F. Forestier, V. Gagnol, P. Ray, H. Paris, Model-based operating recommendations for high-speed spindles equipped with a self-vibratory drilling head , Mechanism and Machine Theory. 46 (2011) 1610–1622

DOI: 10.1016/j.mechmachtheory.2011.07.003

[9] Yamamoto, T., Ishida, Y., Linear and Nonlinear Rotordynamics, New York: Wiley, 2001.
