Numerical Simulation of Masonry Wall under Explosive Load inside

Abstract:

The explosion process of masonry wall under interior explosive load was simulated by adopting the fluid-solid coupling method basing on the software ANSYS/LS-DYNA. The Von Mises stress nephograms and the contrast analysis of the numerical simulation results and test results were presented. The research indicates that mortar elements fails earlier than brick, a little difference exists between the sizes of the blasting hole in X and Y direction because of the transmission of blast wave in brick masonry, the size of blasting hole grows with the increase of weight of charge, and with the increasing charge, the rate of change declined gradually.

• Periodical: Advanced Materials Research (Volumes 712-715)
• Pages: 909-912
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.712-715.909
• Online since: June 2013
• Authors: Juan Juan Liu, Yong Gang Lu, Jin Song Lei
• Keywords: Internal Explosion, Masonry Wall, Numerical Simulation

References

[1] J.W. Wesevich and C.J. Oswald. Empirical Based Concrete Masonry Pressure-Impulse Diagrams for Varying Degrees of Damage, ASCE, 2005,207.

DOI: 10.1061/40753(171)207

[2] S.T. Dennis, J.T. Baylot and S.CWoodson, Response of 1/4-scale Concrete Masonry Unit (CMU) Walls to Blast. Journal of Engineering Mechanics, 2002, 128: 134-142.

DOI: 10.1061/(asce)0733-9399(2002)128:2(134)

[3] B.J. Zapata and D.C. Weggel, Collapse Study of An Unreinforced Masonry Bearing Wall Building Subjected to Internal Blast Loading. Journal of Performance of Constructed Facilities, 2008,22 (2):92-100.

DOI: 10.1061/(asce)0887-3828(2008)22:2(92)

[4] X.Y. Wei and Mark G. Stewart, Model Validation and Parametric Study on the Blast Response of Unreinforced Brick Masonry Walls. International Journal of Impact Engineering, 2010, 37 (11):1150-1159.

DOI: 10.1016/j.ijimpeng.2010.04.003

[5] Xingfu Pu, Numerical Analysis on Responses of Elastomer-Reinforced Concrete Masonry Walls Subjected to Blast [D]. Ningbo University, 2008. In Chinese.

[6] C.Wu and H.Hao, Safe Scaled Distance for Masonry Infilled RC Frame Structures Subjected to Air-blast loads. Journal of Performance of Constructed Facilities, 2007, 21 (6):422-431.

DOI: 10.1061/(asce)0887-3828(2007)21:6(422)

[7] Jingzhen Chang, Yonggang Lu, Yan Zhou, Bin Liang. Journal of Projectiles, Rockets, Missiles and Guidance. 2010(4):83-88. In Chinese.

[8] Sanluo Xu. Journal of Disaster Prevention and Mitigation Engineering.2007,(3):357-362. In Chinese.

[9] Guiqiu Liu. The Research on the Basic Mechanical Behavior of Masonry Structure[D]. Hunan University,2005. In Chinese.

[10] X.Q. Zhou, H. Hao. Numerical Modeling of Response and Damage of Masonry Walls to Blast Loading [J]. Transactions of Tianjin University.2006,12

[11] Zhengwei Zhang, Erxiang Song, Xinzheng Lu et al. Engineering Mechanics,2008,25(5):73-78. In Chinese.
