Improved Calibration Method of Amplitude and Phase Errors Based on Diagonal Loading

Abstract:

The amplitude and phase errors deteriorate the low-sidelobe level characteristic of phased array antenna, which degrades radar performance seriously. Therefore an improved calibration method of amplitude and phase errors based on diagonal loading is proposed to address the problem of amplitude and phase errors in this paper. Initially, the mathematical models of amplitude and phase errors are developed and the impact of amplitude and phase errors is analyzed. It is found that although the interference can be suppressed when there is amplitude and phase errors in the array, the low-sidelobe level characteristic of adaptive antenna is badly deteriorated. An improved calibration method of amplitude and phase errors based on diagonal loading is proposed. Compared with traditional calibration method, proposed method can reduce the sidelobe level efficiently. At last simulations were carried out to verify the effectiveness of proposed method.

• Periodical: Advanced Materials Research (Volume 717)
• Pages: 359-364
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.717.359
• Online since: July 2013
• Authors: M. Rizwan Anjum, Pi Lei Yin, Peng Fei Shi, F. Ismail
• Keywords: Adaptive Antenna, Amplitude Errors, Calibration Method, Diagonal Loading, Phase Error

References

[1] Alejos. A.V, Dawood. M. Mohammed, H. Sanchez, and M.G "Low sidelobe level radar techniques using Golay based coded sequences," Antennas and Propagation Society International Symposium, 2008. AP-S 2008. IEEE , vol., no., pp.1-4, 5-11 July (2008)

DOI: 10.1109/aps.2008.4619930

[2] Huali. Wang and Hongmei. Zhao "EVM performance evaluation of array channels' amplitude and phase errors for DBF phased array antennas," Phased Array Systems and Technology (ARRAY), 2010 IEEE International Symposium on , vol., no., pp.332-334, 12-15 Oct.( 2010)

DOI: 10.1109/array.2010.5613350

[3] Pazi. L, Leviatan. Y, "Sidelobes Due to Periodic Amplitude and Phase Errors in the Aperture Field of a Radial Waveguide Pin-Fed Array Antenna," Antennas and Propagation, IEEE Transactions on , vol.55, no.1, pp.59-64, Jan ( 2007)

DOI: 10.1109/tap.2006.888446

[4] Gu. Jinghua, Liang. Guang, Gong. Wenbin, Yu. Jinpei "Channel Calibration of Amplitude-Phase Errors of DBF Transmitter Based on Maximum Likelihood Estimation," Networks Security, Wireless Communications and Trusted Computing, 2009. NSWCTC '09. International Conference on , vol.2, no., pp.378-381, 25-26 April (2009)

DOI: 10.1109/nswctc.2009.222

[5] Ou YongQing, Cao Jun, Guo Ling, "Angle selection and dummy internal spacing methods for phased array antenna calibration based on traveling wave technology," Radar Conference, 2005 IEEE International , vol., no., pp.660-662, 9-12 May (2005)

DOI: 10.1109/radar.2005.1435909

[6] Zhu. Liang Yu, Wee. Ser Rahadja, "QR-RLS Based Minimum Variance Distortion less Responses Beamformer," Acoustics, Speech and Signal Processing. ICASSP Proceedings vol.3, no., pp.III, 14-19 May (2006)

DOI: 10.1109/icassp.2006.1660821

[7] Xiaopeng Yang, Pilei Yin, and Tao Zeng, "Mainlobe interference suppression based on large aperture auxiliary array," Antennas and Propagation (APCAP), 2012 IEEE Asia-Pacific Conference on , vol., no., pp.317-318, 27-29 Aug. (2012)

DOI: 10.1109/apcap.2012.6333273

[8] Y. Wang, Q. Ding, and R. Li, "Adaptive array processing". Tsinghua University Press(2009) (in Chinese)
