Conical Surface Sealing Performance of Pipe Connection Fits

Abstract:

The conical surface sealing performance of a pipe connection fit (PCF) has been studied by means of an equivalent mechanical model and the contact finite element analysis (FEA). By building an equivalent mechanical model, we studied the basic mechanical relations between the jointing parts, proposed a sealing mechanism, and identified a basic pretension-relaxation-leakage mode occurring in the sealing process of a conical surface PCF. Then we simulated the contact states of the PCF sealing surface using a multi-body elastic contact finite element method (FEM). In addition, the characteristics of the pretension-relaxation-leakage mode were further discussed in terms of the contact forces as well as the contact areas on the sealing surface. These results revealed some fundamental characteristics inherent in the sealing process of conical surface of PCFs, and demonstrated the potentials of the contact FEA in studying PCF sealing performance.

• Periodical: Advanced Materials Research (Volume 721)
• Pages: 564-571
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.721.564
• Online since: July 2013
• Authors: Ming Xing Qiu, Jian Jun Wang, Zhen Xing Wang, Zhan Ying Li
• Keywords: Contact FEA, Finite Element Method (FEM), Pipe Connection Fit, Relaxation-Leakage Property, Sealing Performance

References

[1] Yanping Peng, Fanchang Zeng, Junjie Wang, etal. The Analysis of Foreign Aviation Titanium Alloy's Development, Application and Feature [J]. Journal of Materials Engineering, 1997. (10) :3-6. In Chinese.

[2] AML Adib, CARP Baptista, MJR Barboza, etal. Aircraft engine bleed system tubes: Material and failure mode analysis[J]. Engineering Failure Analysis, 2007.14, pp.1605-1617

DOI: 10.1016/j.engfailanal.2006.11.053

[3] Junsheng Li, Jianping Luo, Zhongzhi Sun, etal. HB5966-2008: 24 Degree Flare-free Pipe Connection Component General Specification [S]. Beijing: China Aviation Integrated Technology Institute, 2008: 1-14. In Chinese.

[4] Xiaogang Wang, Fangxiao Zhang, Peng Huang. Analysis of Parameters of Pipe Conical Sealing Structure Based on ANSYS[J]. Ordnance Industry Automation, 2009.28(8):25-27. In Chinese.

[5] Xiao-gang WANG, Fang-xiao ZHANG, Peng HUANG. Analysis of Pipe Conical Sealing Structure Matched with Cone-head and Cone-hole Based on ANSYS [J]. Machinery, 2009.36(8):37-40. In Chinese.

[6] Guangbin RAN, Fangxiao Zhang. Robust Design Method of the Sealing Pipe Joint Structure with Double-cone Pipe Union [J]. Lubrication Engineering, 2008.33(5):88-90. In Chinese.

[7] Juntong Xi , Gang Nie, Xuesong Mei, Xutang Wu. Contact FEA of Connection Performance in Pipe Casing Thread Joints, Journal of Xi'an Jiaotong University, 1999.33(11):63-66. In Chinese.

[8] Niuzi HE, Xueshi GAO, Zhaoyong LI. FEA of Thermal Well's Casing Threads Joint, Oil Field Equipment, 2007.36(9):64-66. In Chinese.

[9] Jeroen Van Wittenberghe, Patrick De Baets Wim De Waele. Nonlinear Contact Analysis of Different API Line Pipe Coupling Modifications. Journal of Pressure Vessel Technology 2010, 132 / 051701-1

DOI: 10.1115/1.4001220

[10] ShouJun Chen, Qi An, Yi Zhang, LianXin Gao, Qiang Li. Loading Analysis on the Thread Teeth in Cylindrical Pipe Thread Connection. Journal of Pressure Vessel Technology 2010, Vol. 132 / 031202-1

DOI: 10.1115/1.4000729

[11] Baragetti S. Effects of Taper Variation on Conical Threaded Connections Load Distribution. Transactions of the ASME Journal of Mechanical Design2002, Vol. 124: 320-329

DOI: 10.1115/1.1456459

[12] S. Baragetti,A. Baryshnikov. Rotary Shouldered Thread Connections: Working Limits Under Combined Static Loading. Transactions of the ASME Journal of Mechanical Design,Vol. 123:456-463

DOI: 10.1115/1.1371476

[13] Mingxing QIU, Jianjun WANG, Zhenxing WANG, Zhanying LI, Aviation Pipe Connection Fit's Contact FMA and Its Structure Modification, The 3rd International Conference on Manufacturing Science and Engineering (ICMSE 2012)

DOI: 10.4028/www.scientific.net/amr.472-475.219

[14] HB7000-94, Mount Torque and Test Requirements for Extrusion Flare-free Pipes(1994), Aviation Industry Corporation of China., In Chinese.

[15] Zhenxing WANG. The FEA and Fretting Damage Study of Aero-engine Pipe Connection Fit [D]. Beihang University Dissertation of Master Degree, 2011.10. In Chinese.
