Design of Cleaning Robot Autonomous Charging System

Abstract:

A system of cleaning robots independent charge containing hardware system and software system is designed. The hardware circuit of charging station includes a power supply circuit, the battery constant current charging circuit of charging current which can be regulated by the hardware and software, position coding signal transmitting circuit. This paper also presents a new independent charging algorithm that the robot can search automatically charging station using the random walk model in unknown environment, so that the robot have the ability to find independently the charging station. The results show that the cleaning robot can complete automatic charging, and the success rate is 100%.

• Periodical: Advanced Materials Research (Volume 722)
• Pages: 497-502
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.722.497
• Online since: July 2013
• Authors: Dong Qi Han, Jin Li
• Keywords: Cleaning Robot, Constant Current Source, Independent Charging Algorithm

References

[1] Wan Luanfei. Path Planning of Cleaning Robot and Automatic Charging System He Fei: He Fei University of Technology,(2009)

[2] Wang Jian. Intelligent Structures design of Autonomous Cleaning Robot. Mechanical Research and Application. 2009(4):94-96

[3] Xing Xiaojie. The design of Cleaning Robot System. China Science and Technology. 2010(12):142

[4] Zeng Yantao. Previous and Present Life of Robot. Robot Technique and Application. 2012(2):1-5

[5] Zen Lin. The Research of Embedded Software of the Household Cleaning Robot ID Harbin :Harbin Institute of Technology, (2007)

[6] Lin Dan. A Path Planning Algorithm of Cleaning Robot Indoor.Chong Qing University of Science and Technology Journal 2010,2(1):110-113

[7] Liang Xifeng. The Path Planning of Ground Cleaning Robot Indoor.China Jiliang University Journal. 2006,17(1):64-68

[8] Yu Jianli. Path Planning of Domestic Automatic Moving Cleaning Robot. Journal of ZhongYuan Institute of Technology.2010,21(3):1-3
