Finite-Element Analysis of Effect of Wide-Base Tire on Tire-Pavement Noise

Abstract:

This paper investigates the effect of tire width to tire-pavement noise. A tire-pavement noise numerical model in the near field has been developed using the three-dimensional finite-element method, and performed in the standard FEM code package ADINA. The model is composed of two main components: a rolling tire pavement interaction model and a sound propagation model. The tire width studied ranged from 180 to 210 mm. The computer simulation model was calibrated and validated using experimental results made available from past research. From the simulation results, it was found that tire width has a noticeable effect on tire-pavement noise. In particular, it was found that tires with wider base were found to produce higher noise levels.

• Periodical: Advanced Materials Research (Volume 723)
• Pages: 105-112
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.723.105
• Online since: August 2013
• Authors: Jia Sheng Yang, Tien Fang Fwa, Ghim Ping Ong, Chye Heng Chew
• Keywords: Finite Element Analysis (FEA), Tire-Pavement Noise, Wide-Base Tire

References

[1] D. Gibbs, R. Iwasaki, R. Bernhard, J. Bledsoe, D. Carlson, Quiet Pavement Systems in Europe, Federal Highway Administration, 2005.

[2] U. Sandberg, J. A. Ejsmont, Tire/Road Noise Reference Book, Informex, Kisa, Sweden, 2002.

[3] U. Sandberg, Tyre/Road Noise - Myths and Realities, Holland, Internoise, 2001.

[4] H. Steven, H. Pauls, Entwicklung eines Messverfahrens für das Reifen-Fahrbahn Gerausch. Report from FIGE, Herzogenrath, Germany, 1990. (In German)

[5] J. A. Ejsmont, S. Taryma, Halas Opon Samochodow Osobowych Poruszajacych Sie Posuchych Nawierzchniach asfaltowych I Betonowych, Ph.D Thesis, Technical university of Gdansk, Poland, 1982. (In Polish)

[6] M. Brinkmeier, U. Nackenhorst, O. von Estorff and S. Petersen. A Finite Element Approach for the Simulation of Tire Rolling Noise, Journal of Sound and Vibration, 309 (2008) 20-39.

DOI: 10.1016/j.jsv.2006.11.040

[7] K. Yum, K. Hong, J. S. Bolton, Influence of Tire Size and Shape on Sound Radiation from a Tire in the Mid-Frequency Region, SAE 2007 Noise and Vibration Conference and Exhibition, St. Charles, IL, USA, 2007.

DOI: 10.4271/2007-01-2251

[8] ANSYS, Inc. ANSYS, Inc. Theory Reference. ANSYS, Inc., Canonsburg, 2004.

DOI: 10.1016/b978-0-12-811768-2.00022-5

[9] M. A. I. Baig, A Consistent Segment Procedure for solution of 2D Contact problem with Large Displacement, PHD Thesis, Massachusetts Institute of Technology, 2006.

[10] C. Wagner, T. Huttl, P. Sagaut, Large-Eddy Simulation for Acoustics, Cambridge University Press, Cambridge, 2007.

[11] J. W. Deardorff, A numerical study of three-dimensional channel flow at large Reynolds numbers, Journal of Fluid Mechanics, 41 (1970) 453–480.

DOI: 10.1017/s0022112070000691

[12] L. G. Olson, K. J. Bathe. An infinite element for analysis of transient fluid-structure interactions, Engineering Computations, 2 (1985) 319-329.

DOI: 10.1108/eb023631

[13] K. J. Bathe, H. Zhang, A mesh adaptivity procedure for CFD and fluid-structure interactions, Computers Structures, 87 (2009) 604-617.

DOI: 10.1016/j.compstruc.2009.01.017

[14] PIARC, Specification for a Standard Test Tire for Friction Coefficient Measurement of a Pavement Surface: Smooth Test Tire, World Road Association, 2004.

[15] U. Sandberg, J. A. Ejsmont, Tire/Road Noise on Rubberized Asphalt and Cement Concrete Surfaces in Sweden, 1990.

[16] J. A. Ejsmont, P. Mioduszewski, Certificatoin of Vehicles Used for Tire/Road Noise Evaluation by CPX Method, Noise Control Engineering Journal, 57 (2009) 2009.

DOI: 10.3397/1.3081292

[17] P. Kindt, D. Berckmans, F. De Coninck, P. Sas and W. Desmet, Experimental analysis of the structure-borne tire/road noise due to road discontinuities, Mechanical Systems and Signal Processing, 23 (2009) 2557-2574.

DOI: 10.1016/j.ymssp.2009.04.005

[18] B. S. Kim, C. H. Chi, T. K. Lee, A study on radial directional natural frequency and damping ratio in a vehicle tire, 68 (2007) 538-556.

DOI: 10.1016/j.apacoust.2006.07.009
