A PV Cell Mathematical Model and MPPT Algorithm in PSCAD

Abstract:

This paper proposes a modified equation-based model for a PV cell to get the best I-V characteristic comparing with the points taken directly from the manufacturer’s published curves. Based on the model discussed in [1, 3], a modified mathematical equation is put forward taking the changes of environmental parameter into account. Moreover, on the basis of Boost-circuit, an optimized initial Duty Circle is proposed. The initial data varies with the different temperature and irradiance. This method can result in a high speed MPPT. To validate the model accuracy and the MPPT efficiency, the elements library about PV system has been developed in PSCAD software. A particular typical 200W photovoltaic panel (KC200GT) is used in simulation. By comparing with the general model and manufacturer’s datasheet, the simulation results show excellent correspondence to the modified model. The improved MPPT module in PSCAD can track the maximum power point quickly and exactly.

• Periodical: Advanced Materials Research (Volumes 724-725)
• Pages: 10-16
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.724-725.10
• Online since: August 2013
• Authors: Li Mei Xu*, Chao Pan, Shi Quan Shao
• Keywords: Maximum Power Point Tracking (MPPT), Photovoltaic (PV) System, Power System Computer Aided Design (PSCAD), PV Cell

References

[1] G Walker, Evaluating MPPT converter topologies using a Matlab PV model. Journal of Electrical & Electronics Engineering, Vol.21, 49-56(2001).

[2] Yushaizad Yusof etc, Modeling and Simulation of Maximum Power Point Tracker for Photovoltaic System, National Power &: Energy Conference 2004 Proceedings, 88-91.

DOI: 10.1109/pecon.2004.1461622

[3] Jianhui Su, Shejie Yu , WeiZhao etc, Investigation On Engineering Analytical Model Of Silicon Solar Cells .ACTA ENERGIAE SOLARIS SINICA, Vol.22 ,409-412(2001 ).(In Chinese)

[4] Changjiang Wang, Versatile Model for Photovoltaic Cell Based on MATLAB, Electric Power Science and Engineering, Vol.25, 11-14(2009). (In Chinese)

[5] Marcelo Gradella Villalva, Jonas Rafael Gazoli etc. Comprehensive Approach to Modeling and Simulation of Photovoltaic Arrays, IEEE TRANSACTIONS ON POWER ELECTRONICS, Vol. 24, 1198-1204(2009).

DOI: 10.1109/tpel.2009.2013862

[6] Dejia Zhou , Zhengming Zhao etc. Analysis characteristics of photovoltaic arrays using simulation. J T singhua Univ (Sci & Tech), Vol.47, 1109 – 1112(2007). (In Chinese)

[7] Liping Wang etc. An improved MPPT algorithm based on PV cells mathematical model, Journal of North China Electric Power University, Vol.38, 12-16(2011). (In Chinese)
