Vibration Analysis on the Megawatt-Class Wind Turbine Based on the Rigid-Flexible Coupling Model

Abstract:

The rigid-flexible coupling model of wind turbine was established in ADAMS to study the vibration characteristics, which was based on the working principle of megawatt wind turbine. The natural frequencies and vibration modes of the tower have been obtained by dynamic simulation analysis and vibration analysis of the wind turbine. The comparison of the first-order bending natural frequency by raley analysis algorithm and the first-order bending natural frequency by the software, which has validated the correctness of rigid-flexible coupling model of wind turbine, the analysis of vibration characteristic has verified the rationality of the structure of the wind turbine.

• Periodical: Advanced Materials Research (Volumes 724-725)
• Pages: 517-521
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.724-725.517
• Online since: August 2013
• Authors: Jia Qiang E, Yan Chen, Shui Hui Wang, Zhen Qiang Li, Cheng Qian
• Keywords: Natural Frequency, Rigid-Flexible Coupling Model, Vibration Mode, Wind Turbine (WT)

References

[1] CHEN Ming, YANG Gang. The Wind Power Generation Technology and Its Development Prospect[J]. JOURNAL OF ELECTRIC POWER, 2008, 23(4): 272-275. (in Chinese)

[2] YU Yi. Performance analysis and research of sliding yaw bearing in the wind turbine[D]. Beijing: North China Electric Power University, School of Energy, Power and Mechanical Engineering, 2011. (in Chinese)

[3] E Jia-qiang, ZHANG Bin. Dynamics simulation and analysis on new wind power yaw reducer[J]. Journal of Central South University(Science and Technology), 2011,42(8):2324-2331. (in Chinese)

[4] DAI Jian-xin. Finite element modeling and analysis of static and dynamic characteristics of wind turbine tower[D]. Lanzhou: Lanzhou University of Technology, School of Energy and Power Engineering, 2011. (in Chinese)

[5] ZHANG Suohuai, ZHANG Wenli, ZHANG Qinglei. Dynamic model of MW grade wind turbine based on Adams[J]. JOURNAL OF NORTH CHINA ELECTRIC POWER UNIVERSITY, 2009, 36(4): 51-57. (in Chinese)

[6] JIA Chengshuang, Research on the Vibration of the Wind Turbine when Yawing[D]. Jilin: Jilin University, School of Mechanical Engineering, 2011. (in Chinese)

[7] TONG Yue. The finite element analysis of loads and vibrations on horizontal axis wind turbine[D]. Lanzhou: Lanzhou University of Technology, School of Energy and Power Engineering, 2011. (in Chinese)

[8] ZHU Zhen-min. Analysis and guard of vibration for the MW grade wind turbines[D]. Lanzhou: Lanzhou University of Technology, School of Mechanical and electrical engineering, 2008. (in Chinese)

[9] CHEN Rong-sheng. The structural dynamics research of wind turbine[D]. Chengdu: XiHua University, 2009. (in Chinese)

[10] LI Hui-xin. Lateral load and dynamic research of horizontal axis wind turbine[D]. Shantou: Engineering School of Shan Tou University, 2009. (in Chinese)

[11] LIAO Mingfu, HUANG Wei. Unstable torsional vibraton of wind turbines caused by nacelle yawing[J]. ACTA ENERGIAE SOLARIS SINICA, 2009, 30(4): 488-492. (in Chinese)

[12] Søren Stubkier, Henrik C. Pedersen.Design, Optimization and Analysis of Hydraulic Soft Yaw System for 5 MW Wind Turbine[J].2011, 35(5): 529-550.

DOI: 10.1260/0309-524x.35.5.529

[13] Tolou N., Khatam I., Jafari B. Analytical Solution of Nonlinear Vibrating Systems[J]. American Journal of Sciences, 2008.

DOI: 10.3844/ajassp.2008.1219.1224
