Study of the Emergency DC Power Support Strategy Based on the Principles of the Generalized Dynamics

Abstract:

Emergency HVDC power support (EDCPS) can be used for improving the transient stability of AC/DC power systems, but the effect is directly determined by the quantity, the starting time, the speed and other factors of the power support. In this article, the dynamic characteristics of AC/DC power systems after a fault are analyzed, generalized dynamical models of the AC/DC power system are established, the relationship between the duration and the quantity of the EDCPS and the dynamic characteristics of the system are established based on the impulse theorem, then the EDCPS strategy besed on the principles of the generalized dynamics is proposed. At last, it is verified by examples of simulation that the strategy can effectively improve the stability of the AC/DC power systems after a fault.

• Periodical: Advanced Materials Research (Volumes 732-733)
• Pages: 719-725
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.732-733.719
• Online since: August 2013
• Authors: Jian Tao Liu, Chen Long Li, Ke Wang
• Keywords: AC/DC Power Systems, Emergency Power Support, HVDC, Impulse Theorem

References

[1] Ke Wang, Shengchun Yang, Jianguo Yao, Yaping Li. Emergency DC Power Support with Reactive Power Coordinated Control for Multi-circuit HVDC Systems [J]. Automation of Electric Power Systems, 2011, 18: 103-107.

DOI: 10.1109/psce.2011.5772475

[2] LEE R L, MELVOID DJ, SZOMLAS D J, et al. Potential DC system support to enhance AC system performance in the Western United States [J]. IEEE Trans on Power System, 1993, 8(1): 264-274.

DOI: 10.1109/59.221231

[3] Zheng Xu, Huimin Gao, Jingping Yang. Effect of HVDC Emergent Power Modulation in South China Power System [J]. High Voltage Engineering, 2004, 11: 24-26.

[4] Weidong Yang, Yusheng Xue, Yong Jing, et al. Emergency DC Power Supportto AC Power System in the South China Power Grid [J]. Automation of Electric Power Systems, 2003, 17: 68-72.

[5] Weidong Yang. Research on Control Strategies for Multi-Infeed HVDC Systems [D]. Zhejiang University, (2001).

[6] Huifan Xie, Yao Zhang, Chengjun Xia. Study of UHV emergency DC power support strategy [J]. Electric Power Automation Equipment, 2008, 08: 1-7.

[7] Huifan Xie Yao Zhang, Chengjun Xia. Optimization Strategy of Emergency DC Power Support Based on Extended Equal Area Criterion [J]. Journal of South China University of Technology (Natural Science Edition), 2008, 06: 127-132.

[8] Yubo Zhan. Influence of Emergency DC Power Support for AC/DC System Transient Stability [D]. Shenyang University of Technology, (2011).

[9] Yun Zeng, Zuyi Shen, Linning Cao. Theoretical Study on Dynamical Model of Single-machine-infinite-bus System [J]. Proceedings of the CSEE, 2008, 17: 138-143.

[10] Liantao Ji, Jiancheng Zhang. Research on Generalized Momentum Compensation Method of Flywheel Energy Storage in Renewable Energy Power System [J]. Proceedings of the CSEE, 2010, 24: 101-106.

[11] Huawei Luo. Power System Static Voltage Stability Analysis Base on Fast Thevenin Equivalent [D]. Hunan University, (2009).

[12] Zheng Xu. Dynamic behavior analysis of AC / DC power system [M]. China Machine Press, (2004).
