Artificial Ground Freezing for Rehabilitation of Tunneling Shield in Subsea Environment

Abstract:

Artificial ground freezing method was employed in the rehabilitation project of a subsea tunnel. To ensure safety of the subsea rehabilitation work, special design and research were conducted considering the unfavorable influence of the salt in seawater had on freezing effect, such as thickness thinning and strength loss of the frozen wall. A shell-shaped frozen soil wall was designed to cut off the leakage channel into the shield. Double rows of vertical freezing pipes with limited-depth freezing were settled in front of the cutter head, and auxiliary freezing pipes were settled at the sides of the shield to achieve the design goal. Results of analyzing monitoring data on frozen soil temperature showed that the design was reasonable for shield rehabilitation in subsea stratum.

• Periodical: Advanced Materials Research (Volumes 734-737)
• Pages: 517-521
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.734-737.517
• Online since: August 2013
• Authors: Xiang Dong Hu*, Luo Yu Zhang
• Keywords: Artificial Ground Freezing (AGF), Seawater Freezing, Shield Rehabilitation, Subsea Environment, Temperature Monitoring

References

[1] Chen Tao, Hu Xiang-dong, Application of Vertically Freezing Reinforcement in Recovery Works of Shield Tunnel, Journal of Hefei University of Technology. 32(2009) 1542-1546. (in Chinese)

[2] Hu Xiangdong, Experimental Research on Properties of Artificially Frozen Soil in the Port Area for Project of the Subsea Cable Tunnel in Shantou. Shanghai, Dept. of Geotechnical Engineering, Tongji University.(2008) (in Chinese)

[3] Hu Xiangdong, Huang Feng, Bai Nan, Models of Artificial Frozen Temperature Field Considering Soil Freezing Point, Journal of China University of Mining and Technology. 37(2008) 550-555. (in Chinese)

[4] Hu Xiangdong, Zhao Junjie, Research on Precision of Bakholdin model for Temperature Field of Artificial Ground Freezing, Chinese Journal of Underground Space and Engineering. 6(2010) 96-101. (in Chinese)

[5] Zhang Jun, Li Muhan, Hu Xiangdong, Safety State Assessment Method of Artificially Frozen Soil Curtain in Saline Strata and Its Application, Chinese Journal of Underground Space and Engineering, 6(2010) 189-192. (in Chinese)

[6] Hu Xiang-dong; Liu Rui-feng, Temperature Monitoring System for Freezing Method based on "1-Wire Bus", Chinese Journal of Underground Space and Engineering, 3(2007) 937-940. (in Chinese)
