Study on Structure and Performance Optimization for Spherical Stern Bearing Based on ANSYS

Abstract:

Spherical stern bearing is kind of new bearing, which combines ordinary water lubricated stern bearing with sphere bearing. It has function to adjust contact situation of stern bearing and stern shaft automatically, decreases pressure peak, leads to pressure distribution on the bearing being more uniform, helps to overcome the problem of local overload to avoid edge effect and improves damping performance. On the base of the ANSYS software, the contact deformation and pressure calculation of spherical stern bearing are carried out to compare with ordinary stern bearing and analyse the effectiveness of reducing pressure on bearing, optimization problems of the sphere position and sphere diameter are discussed, which shows that the contact pressure achieves a minimum when the sphere is located at intermediate position of bearing bush and the maximum contact pressure decreases with the increase of sphere diameter, and they have linear relation.

• Periodical: Advanced Materials Research (Volume 744)
• Pages: 44-48
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.744.44
• Online since: August 2013
• Authors: Wei Jing Chen, Zheng Lin Liu, Sheng Dong Zhang, Liang Zhao, Peng Liu
• Keywords: Optimization, Spherical Stern Bearing, Vibration Damping, Water Lubricated

References

[1] Xia Zhang, Xinrong Wang, et al. The research actuality and development trends of water lubricated bearings[J]. Equipment Manufacturing Technology, 2008 (1) : 101-102.

[2] Ship Inspection Bureau of the People's Republic of China. The ship vibration control guides [M] Beijing: People's Communications Press, (2000).

[3] Yingchun Wei, Zhuanping Li, Ning Chang. Research on vibration test of water lubrication spherical stern bearing[J]. Ship ocean engineering, 2012 (4) : 123-125.

[4] Dinghan Xiang, Chunyan Wang, et al. Structural Optimization and Friction and Wear Behavior of a Radial Sphere Plain Bearing[J]. Tribology, 2004 (6) : 564-567.

[5] Xuejin Shen, Yunfei Liu, et al. The Structure Optimization of Spherical Plain Bearings Based on Taguchi Method[J]. 2012: 94-102.
