Optimizing Design of the Guide-Vane Attached to the New Bidirectional Flowmeter

Abstract:

Performances of vanes with various numbers and front oriented-body with different shapes such as half sphere, half ellipsoid and cone are simulated by RNG κ-ε model and standard wall functions method in order to optimize the parameters of the front oriented-body attached on the new bidirectional flowmeter. The performances of weakening-vortex and the pressure losses attaching to various models are analyzed and compared with each other. The results show that the structure with cone guide-head and 6 vanes can obtain the minimum range of flow pulsation, the least pressure loss and the least reverse flow. The simulation methods and results will be used for reference to analyze the similar annular flow and design the steady device.

• Periodical: Advanced Materials Research (Volume 744)
• Pages: 461-465
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.744.461
• Online since: August 2013
• Authors: Hua Zhi Li, Qian Chao Liang, Han Guo Cui
• Keywords: Computational Fluid Dynamics (CFD), Flowmeter, Front Oriented-Body, Guide-Vane, Parameter Optimizing, Swirling

References

[1] Wuchang Cai, Qijia Ying: The New Instrument of Flowmeter (Chemical industry press, China 2006).

[2] R. K. Singh, S. N. Singh and V. Seshadri, Study on the Effect of Vertex Angle and Upstream Swirl on the Performance Characteristics of Cone Flowmeter Using CFD, Flow Measurement and Instrumentation, Vol. 20, 69-74, (2009).

DOI: 10.1016/j.flowmeasinst.2008.12.003

[3] G. Bobovnik, J. Kutin and I. Bajsic, The Effect of Flow Conditions on the Sensitivity of the Coriolis Flowmeter, Flow Measurement and Instrumentation, Vol. 20, 69–76, (2004).

DOI: 10.1016/j.flowmeasinst.2003.12.001

[4] Yue Liu, Investigation on Inner Cone Flowmeter, Proc. Automation Instrument Journal, Vol. 25, issue 3, 38-41, (2004).

[5] C. J. Bates, B. Franklin, The Performance Characteristics of a Novel Multi-electrode Electromagnetic Fowmeter, Measurement, Vol. 35, 399–408, (2004).

DOI: 10.1016/j.measurement.2004.03.008

[6] ASME: Fluid Meters, Vol. 1, 182, (1971).

[7] Liu Zhengxian, Xu Lianhuan, Structure and Performance of Front Oriented-Body in Turbine Flowmeter, Chinese Journal of Mechanical Engineering, Vol. 44, issue 1, 233-237, (2008).

DOI: 10.3901/jme.2008.01.233

[8] Huazhi Li, Qianchao Liang, Hanguo Cui, Research on the Meter Coefficient and Simulation Analysis of a New Swirlmeter, Applied Mechanics and Materials, Vol. 127, 421-427, (2011).

DOI: 10.4028/www.scientific.net/amm.127.421

[9] Wang Fujun: Principle and Apliance of Computational Fluid Dynamics (CFD) ( Tsinghua University Press, China 2004).
