Simulation of the Global Response of Welded Joint Using Digital Image Correlation Measurement

Abstract:

The effect of the mechanical heterogeneity on the global and local tensile properties of laser-arc hybrid welded joints in industrial pure aluminum has been investigated. Digital image correlation method has been used during tensile test for mapping the strain distribution and to determine the local stress-strain curves of FZ and HAZ. The tensile properties of the various regions are very heterogeneous and HAZ is the weakest region because of the strain localizes during tensile test. Finite element technique was used to model the global response of welded joint based on local constitutive properties which could be determined from DIC results.

• Periodical: Advanced Materials Research (Volume 749)
• Pages: 597-600
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.749.597
• Online since: August 2013
• Authors: Chao He, Shi Ming Cui, Yan Zeng Wu, Ze Fu Luo, Qingyuan Wang
• Keywords: Digital Image Correlation (DIC), Finite Element Technique, Mechanical Heterogeneity, Welded Joint

References

[1] Lemmen HJK, Alderliesten RC, Benedictus R, Hofstede JCJ, Rodi R. The power of digital image correlation for detailed elastic–plastic strain measurements. In: WSEAS international conference on engineering mechanics, structures, engineering geology. Crate Island, Greece; (2008).

[2] Sutton MA, Yan JH, Avril S, Pierron F, Adeeb SM. Identification of heterogeneous constitutive parameters in a welded specimen: uniform stress and virtual fields methods for material property estimation. Exp Mech Vol. 48(2008), pp.351-364.

DOI: 10.1007/s11340-008-9132-6

[3] Lockwood WD, Tomaz B, Reynolds AP. Mechanical response of friction stir welded AA2024: experiment and modeling. Mater Sci Eng A Vol. 323(2002), p.348–353.

DOI: 10.1016/s0921-5093(01)01385-5

[4] Molak RM, Paradowski K, Brynk T, Ciupinski L, Pakiela Z, Kurzydlowski KJ. Measurement of mechanical properties in a 316 L stainless steel welded joint. Int J Press Vessels Pip Vol. 86, p.43–47.

DOI: 10.1016/j.ijpvp.2008.11.002

[5] W.J. Wolters, M.A. Sutton, W.H. Peters, W.F. Ranson, S.R. McNeill, Computer Vision Vol. 8 (1983), pp.133-139.

[6] H.A. Bruck, S.R. McNeill, M.A. Sutton, W.H. Peters, Exp. Mech. Vol. 29 (1989), pp.261-267.

[7] W.D. Lockwood, A.P. Reynolds, Simulation of the global response of a friction stir weld using local constitutive behavior, Materials Science and Engineering A Vol. 339 (2003), pp.35-42.

DOI: 10.1016/s0921-5093(02)00116-8

[8] M. Babai, J. Jang, S.R. McNeill, M.A. Sutton, Opt. Eng. Vol. 27(1988).
