Model-Based Design of UAV Autopilot Software

Abstract:

This paper presents a Model-Based approach to develop UAV (Unmanned Aerial Vehicle) autopilot software. It employs Simulink to design the flight controller, Stateflow to implement control logic and Matlab coder to automatically generate embedded C code from the model developed. Software in the loop (SIL) and hardware in the loop (HIL) simulations are performed in the laboratory to validate the software developed. Flight trial cost and risks are minimized and the design cycles are greatly shortened. The feasibility and the effectiveness of the approach are verified through results from lab simulations and field trials.

• Periodical: Advanced Materials Research (Volumes 756-759)
• Pages: 2115-2119
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.756-759.2115
• Online since: September 2013
• Authors: Ming Zuo, Ying Liu, Yi Qian, Xiong Wen Hu, Xiao Chuan Zhao, Jin Hua Wang
• Keywords: Flight Control, Model-Based Design, Simulation, UAV

References

[1] Yang Xiangzhong, Cui Wenge. Research on Flight Control System Integral Design Based on Model[J]， Journal of System Simulation, 2007, 19(19): 4411-4416.

[2] Zhang Zhisheng, Chen HuaiMin. The Modeling and Simulation of SUAV's Control Logic[J], Fire Control & Command Control, 2010, 35(9): 93-97.

[3] Li Junmei, Cheng Yongmei,. Research of multi-mode flight simulation based on Stateflow [J], Application Research of Computers, 2011, 28(12): 4557-4559.

[4] Wang Geng, Jia Wei. Implementation of One UAV Flight Control Testing System Based on Simulink and DSP[J], Journal of Projectiles, Rockets. Missiles and Guidance, 2008, 28(1): 286-288.

[5] Widyawardana Adiprawita, Adang Suwandi Ahmad. Hardware In The Loop Simulator in UAV Rapid Development Life Cycle, International Conference on Intelligent Unmanned Systems (ICIUS), 2007 Indonesia, 31-36.
