Mix-Subdivision Dynamic Terrain Visualization Algorithm

Abstract:

Dynamic Terrain is becoming more and more important in ground-based simulation systems. In military simulation systems, craters and ruts can improve the reality. In this paper, a dynamic terrain visualization method based on quadtree and multi-resolution voxel is presented in order to realize the real-time rendering for realistic craters in battlefield. Quadtree is selected as our basic data structure and mix-subdivided according to the size of the terrain. Scene tree is recursive subdivided according to both the distance between the node and camera and error criterion. Vertex is removed to solve the cracks and linear interpolation to solve popping in the algorithm. We also implement the visualization of craters through combining our algorithm with the physical model of craters based on multi-resolution voxel. The implementation results prove that the method are feasible and efficient.

• Periodical: Advanced Materials Research (Volumes 756-759)
• Pages: 3372-3377
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.756-759.3372
• Online since: September 2013
• Authors: Xiao Hui Zhao, Bao Di Xie, De Peng Wan, Qing Yun Wang
• Keywords: Dynamic Terrain, Mix-Subdivision, Multi-Resolution Voxel, Quadtreet

References

[1] Willem H. de Boer. Fast Terrain Rendering Using Geometrical MipMapping, (2000).

[2] Duchaineau M, Wolinsky M, et al. ROAMing Terrain: Real-time Optimally Adapting Meshes. In Proceedings of IEEE Visualization 1997, 1997: 81-88.

DOI: 10.1109/visual.1997.663860

[3] Hoppe H. View-dependent refinement of progressive meshes. In Proceedings of SIGGRAPH 1997, 1997: 189-198.

[4] Huaiqing He, Chong Wang, et al. An Improved Approach on Visualization of Large-Scale Terrain Surface. In Proceedings of CGIV, 2007. 2007: 481-488.

DOI: 10.1109/cgiv.2007.17

[5] Xingquan, Cai, Jinhong Li, A-Real-time Visualization of Dynamic Terrain in Off-road Driving Simulation.
