Supervisory Control of Silicon Steel Plant Dust Removal System Based on Configuration Technology

Abstract:

This paper introduces the real-time monitoring provided by the function of PLC control system based on the configuration control technology in silicon steel plant. Visual real-time monitoring of silicon steel flue gas dust removal system, the main parameters includes: working condition of the two temperature sensor in flue pipe, air conditioning butterfly valve, bag type dust trap system, high pressure fan, dust conveying system, dust unloading system and cleaning system, etc. Moreover, monitoring and give an alarm in case the failure of dust removal system appears appears in the course of their work. This paper also introduces the hardware components and software components of the visual real-time monitoring of silicon steel flue gas dust removal system, and their applications. And discuss how to use configuration technology develop and design real-time monitoring system.

• Periodical: Advanced Materials Research (Volumes 756-759)
• Pages: 452-457
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.756-759.452
• Online since: September 2013
• Authors: Li Jun Yang
• Keywords: Configuration Technology, Dust Removal System, Supervisory Control

References

[1] Liao Changchu, in: Programming and Application of PLC, edtied by China Machine Pres, Beijing, M(2003), in press.

[2] Wu Zuoming, in: MCGS & PLC Application and Technology, edtied by Beihang University Press, Beijing, M(2007), in press.

[3] Xu Zhijun, in: MCGS And Application, edtied by China Machine Pres, Beijing, M(2003), in press.

[4] Gong Lixian and Zhang Zhejun: Application And Development Trend of Precipitator In Power Plant (Thermoelectric Technology, J 2010(02).

[5] Hu Jia, Xia Yongjun and Fu Yongwei: Analysis of An Iron And Steel Enterprise Transformation of Thermal Power Plant of Bag Type Dust Collector(Metallurgical Power, J 2013(1).

[6] Jiang Dehou, Hao Dangqiang and Wang Qin: Influence Factors of Coal-fired Power Plant Development Trend of bag Filter And Its Operational Life ( China Electric Power, J 2008(5) ).
