The Model of Distributed Grid-Connected DC Micro Network Inverters and Double Loop Control Method

Abstract:

In this paper, for parallel operation of the three-phase PWM inverter control system, we put forward and set up the equivalent grid inverter mathematical model. In the process of grid inverter equivalent model is discussed, for the three-phase inverter system is a nonlinear system, in order to facilitate the performance of the system analysis and design of the control system, the transfer function of the system were analyzed to the linearized system. After the linearization control the theory system can be discussed using the method of classical. On the premise of system average model we get the static working point system, according to the law of small signal, we can obtain the small signal mathematical model .At the same time, discusses the three phase inverter design of double loop control system.

• Periodical: Advanced Materials Research (Volumes 760-762)
• Pages: 1131-1135
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.760-762.1131
• Online since: September 2013
• Authors: Jian Ye Liu, Chang Ge Tian, Shan Shan Jiang, Zhi Peng Ge
• Keywords: Double Loop Contrl, Equivalent Model, Small Signal Mathematical Model, System of Linear, Three-Phase PWM Control

References

[1] Cassiano Rech, Humberto Pinheiro, Hilton Abilio Grundling et al. Comparison of Digital Control Techniques With Repetitive Integral Action for Low Cost PWM Inverters. IEEE TRANSACTIONS ON POWER ELECTRONICS, JANUARY 2003, 18(1): 401~410.

DOI: 10.1109/tpel.2002.807094

[2] Xia xiangyang , Luo'an, Shanghongzhong, Modeling of parallel hybrid active filter[J]. High voltage technology, 2007, 33(9): 146-149.

[3] Rech C, Pinheiro H, Grundling H A, et a1．Comparison of digital control techniques with repetitive integral action for low Cost PWM inverters[J]. IEEE Transactions on Power Electronics 2003. 18(1)：401·410.

DOI: 10.1109/tpel.2002.807094

[4] Chan C C, Zheng Ming Zhao, Qian C, et al . Comparisons of PWM and One Cycle Control for Power Amplifier withMultilevel Converter [J] . IEEE Trans on Ind Electronics, 2002 , 49 (6) : 1342-1344.

DOI: 10.1109/tie.2002.804988

[5] Jong-Lick Lin. A new approach of Dead-Time compensation for PWM voltage inverters[J]. IEEE transactions on circuits and systems i: fundamental theory and applications, 2002, 49(4): 476~483.

DOI: 10.1109/81.995662

[6] Mohamed S.A. Dahidah, Vassilios G. Agelidis, Machavaram V. Rao. Hybird genetic algorithm approach for selective harmonic control[J]. ELSEVIER, Energy Conversion and Management, (2007).

DOI: 10.1016/j.enconman.2007.06.031

[7] Lie Xu, Dawei Zhi , Liangzhong Yao. Direct Power Control of Grid Connected Voltage Source Converters[J]. IEEE. 2007: 1-6.

DOI: 10.1109/pes.2007.385753

[8] H polinder, P Van Der, F A Frank. Comparison of direct-drive and geared Generator concepts for wind turbines. IEEE Transactions on Energy Conversion, 2006, 21(3): 725-733.

DOI: 10.1109/tec.2006.875476
