3-D Simulation of Remote Field Eddy Current Detection for Stress Corrosion Cracks in Pipeline

Abstract:

Three-dimensional (3-D)finite element simulation models are conducted to simulate the in-serviceinspection of the axial stress corrosion cracking (SCC) in ferromagneticpipeline using remote field eddy current (RFEC) probes. In this paper, atypical remote field eddy current probe which is internal to and coaxial withthe pipe is firstly introduced. Then a 3-D finite element simulation model isestablished in ANSYS to analyze the detection of RFEC technology. Finally theRFEC signals are observed when changing the geometric parameters, and thedefinite influences of crack size on the amplitude and phase lag of REFCsignals are evaluated. The results of the investigations are beneficial to thedetection and sizing of SCC in pipelines

• Periodical: Advanced Materials Research (Volumes 760-762)
• Pages: 1154-1158
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.760-762.1154
• Online since: September 2013
• Authors: De Hui Wu, Zhong Yuan Zhang, Zhen Liang Liu, Xiao Hao Xia
• Keywords: Pipeline, Remotefield Eddy Current (RFEC), Simulation, Stress Corrosion Cracking (SCC)

References

[1] Qi Jiang: submitted to Journal of testing and evaluation (2010).

[2] Zhenmao Chen, Yusa Noritaka, and Miya Kenzo: submitted to Nondestructive testing and evaluation (2009).

[3] Schempf Hagen, Mutschler Edward, and Gavaert Alan: submitted to Journal of field robotics ( 2010).

[4] Binfeng Yang, Xuechao Li: submitted to Nondestructive Testing and Evaluation (2010).

[5] D.L. Atherton, L. Clapham, and W. Czura etc.: submitted to Research in nondestructive evaluation (1996).

[6] Jin-Jhy Jeng: submitted to Japanese Journal of Applied Physics (2005).
