Current Source Design for 3D Magnetic Field Simulation

Abstract:

This paper designs a current source which is used for simulating the three dimensional magnetic field. Gives the circuit schematic, Analyzes the design principle of the circuit and puts forward the calibration method of software which is suitable for the operation in microprocessor and improves the output accuracy of the constant current source. Actual test shows that the output of the constant current source is 0.1mA-500mA and the precision error is less than 0.03% of full scale. It has been used in the degaussing device testing and maintenance. The performance is stable and reliable achieves good results.

• Periodical: Advanced Materials Research (Volumes 760-762)
• Pages: 1354-1359
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.760-762.1354
• Online since: September 2013
• Authors: Zhi Li, Shu Bao Pan
• Keywords: Current Source, DDS, Helmholtz Coil

References

[1] Nak. Sun. Choi, Giwoo. Jeung, Sang. Sik. Jung, Chang. Seob. Yang, Hyun. Ju. Chung, and Dong. Hun. Kim, Efficient Methodology for Optimizing Degaussing Coil Currents in Ships Utilizing Magnetomotive Force Sensitivity Information．IEEE Transactions on Ma gnetics, Vol. 48, No. 2, Feb (2012).

DOI: 10.1109/tasc.2011.2180296

[2] W. Venturini Delsolaro, L. Bottura, M. Haverkamp, and A. Kuijper, Degaussing and Decay Reduction in the Short Superconducting Dipole Models for the LHC. IEEE Transations on Applied Supercondutity, Vol. 12, No. 1, Mar (2002).

DOI: 10.1109/tasc.2002.1018403

[3] Paul Annus, et al, Excitation Current Source for Bioimpedance Measurement Applications: Analysis and Design,. IEEE Instrum and Meas Technology Conference, pp.848-853, (2008).

DOI: 10.1109/imtc.2008.4547155

[4] Yu Peng, Yanchao Xia, Shaojun Wang, Design of a High Precision Current Source. The Ninth International Conference on Electronic Measurement & Instruments, vol, (2009).

[5] Luo Xiaoqiao, Zhou Lili, Design of Intelligence Current Source with High Precision and Wide Range, Journal of IEEE. Vol 26, NO 6, Dec (2004).

[6] Yong Shao, Enyu Jiang, Quanzhen Huang, Xiangqiang Zeng, Development of Constant Current Source for SMA Wires Driver Based on OPA549 , International Conference on Life System Modeling and Simulation & 2010 International Conference on Intelligent Computing for Sustainable Energy and Environment, Sep (2010).

DOI: 10.1007/978-3-642-15621-2_12

[7] B. D. Yang, Y. K. Shin, J. S. Lee, Y. K. Lee, and K. C. Ryu, Anaccurate current reference using temperature and process compensation current mirror, in Proc. Asian Solid-State Circuits Conf. (A-SSCC), p.241–244, (2009).

DOI: 10.1109/asscc.2009.5357223

[8] Xu Keqiang, Design of digital control direct circuit current source in high accuracy and wide range, Journal of Chongqing Technology and Business Univ. Vol. 23, No 2, (2006).

[9] R. H. Hong, M. Rahal, A. Demosthenous, and R. H. Bayford, Floating Voltage-Controlled Current Source for Electrical Impedance Tomography, European Conference on Circuit Theory and Design 2007, pp.208-211. Seville, Spain, Aug. 26 - 30, (2007).

DOI: 10.1109/ecctd.2007.4529573
