FE Simulation of Die Forging Process for High Pressure Valve Body

Abstract:

In this paper, based on the finite element (FE) software Deform 3D, the simulation of the die forging process of a high pressure valve body was conducted. The deformation field and the metal flow field of billet were obtained and analyzed in detail. In addition, the effect of upsetting depth on the die forging process of high pressure valve body was also discussed. This study can provide a good guide for the following researches and practical industry.
