LXI Precision Time Protocol Applied Research

Abstract:

In order to meet the real-time demands of some equipment networked test, the time synchronization techniques of ATS based traditional instrument buses are compared with the techniques of LXI ATS. Accordingly,the necessity of LXI ATS time synchronization technique study is put forward. The sorts of time synchronization techniques based on Local Area Network are analyzed. In addition, some methods which could improve the level of LXI data real-time communications are presented. Afterwards, technique realizations of PTP are studied in detail. Local Area Network techniques and IEEE 1588 Precise Time Protocol are adopted in the LXI Automatic Test System which designed in the paper, and the level of time synchronization precision in the system is improved.

• Periodical: Advanced Materials Research (Volume 772)
• Pages: 432-435
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.772.432
• Online since: September 2013
• Authors: Ming Li, Chun Ping Wang, Zhi Qiang Wang
• Keywords: ATS, IEEE 1588, LXI, Time Synchronization

References

[1] Information on http: / www. lxistandard. org.

[2] Information on http: /www. LxiConsortium. org.

[3] IEEE std 802. 3-2002 Carrier sense multiple access with collision detection (CSMA/CD) access method and physical layer specification. (2002).

DOI: 10.1109/ieeestd.1985.82837

[4] EPA criterion for industrial control system, Digital communication for Measurement and control[S]. Beijing: National Standard Committee. (2010).

[5] Wen-Chun Huang, in: The case of Bin-based FPGA-precision clock synchronization method, Journal of Zhejiang University, Engineering Science. (2010).
