Desain Study of Pb-Bi Cooled Fast Reactors with Natural Uranium as Fuel Cycle Input Using Special Shuffling Strategy in Radial Direction

Abstract:

Design study of Pb-Bi cooled fast reactors with natural uranium as fuel cycle input using special radial shuffling strategy has been performed. The reactors utilizes UN-PUN as fuel, Eutectic Pb-Bi as coolant, and can be operated without refueling for 10 years in each batch. Reactor design optimization is performed to utilize natural uranium as fuel cycle input. This reactor subdivided into 6 regions with equal volume in radial directions. The natural uranium is initially put in region 1, and after one cycle of 10 years of burn-up it is shifted to region 2 and the region 1 is filled by fresh natural uranium fuel. This concept is basically applied to all regions. The calculation has been done by using SRAC-Citation system code and JENDL-3.2 library. The effective multiplication factor change increases monotonously during 10 years reactor operation time. There is significant power distribution change in the central part of the core during the BOC and the EOC. It is larger than that in the case of modified CANDLE case which use axial direction burning region move. The burnup level of fuel is slowly grows during the first 15 years but then grow fastly in the rest of burnup history. This pattern is a little bit different from the case of modified CANDLE burnup scheme in Axial direction in which the slow growing burnup period is relatively longer almost half of the burnup history.

• Periodical: Advanced Materials Research (Volume 772)
• Pages: 530-535
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.772.530
• Online since: September 2013
• Authors: Zaki Su’ud, Feriska H. Irka, Taufiq Imam, H. Sekimoto, P. Sidik
• Keywords: Fuel Cycle Input, Long Life Operation, Nitride Fuel, Pb-Bi Cooled Fast Reactor, Radial Shuffling

References

[1] Z. Su'ud and H. Sekimoto, The Prospect of Gas Cooled Fast Reactors for Long Life Reactors with Natural Uranium as Fuel Cycle Input, Annals of Nuclear Energy, Vol. 54 (2013), p.58–66.

DOI: 10.1016/j.anucene.2012.09.014

[2] Zaki Su'ud, Bakrie Arbie, and Sedyartomo S.: The Prospect of MOX Fuel Based Pb-BiCooled Small Nuclear Power Reactors, Progress of Nuclear Energy, Vol. 47 (2005), h. 212-221.

DOI: 10.1016/j.pnucene.2005.05.021

[3] Zaki Su'ud, Neutronic Performance Comparation of MOX, Nitride and Metallic fuel based 25-100 MWe Pb-Bi Cooled Long Life Fast Reactors without on site Refuelling, Progress ofNuclear Energy, Vol. 50 (2008), pp.276-278.

DOI: 10.1016/j.pnucene.2007.11.009

[4] Epung S.B. et al. (2008) Reactor Core Design Optimization Of The 200 MWt Pb-Bi Cooled Fast Reactor for Hydrogen Production, Progress of Nuclear Energy, Vol. 50, pp.434-437.

DOI: 10.1016/j.pnucene.2007.11.027

[5] Zaki Su'ud: Comparative Study on Safety Performance of Nitride Fueled Lead-Bismuth CooledFast Reactor with Various Power Level", Progress in Nuclear Energy Vol. 32 no. 3-4 (1998), pp.571-577.

DOI: 10.1016/s0149-1970(97)00045-0

[6] IAEA TECDOC 1536 Satus of Small Reactors Without On-site Refueling, 2007, 739-759.

[7] Zaki Su'ud, Safety Performance Comparation of MOX, Nitride and Metallic fuel based 25-100MWe Pb-Bi Cooled Long Life Fast Reactors without on site Refuelling, Progress of Nuclear Energy, Vol. 50 (2008), pp.157-162.

DOI: 10.1016/j.pnucene.2007.10.028

[8] Zaki Su'ud and H. Sekimoto: A concept of Long-life Small Safe Reactor, SR/TIT '91: International Specialist Meeting on Potentials of Small Nuclear Reactors for Future Clean and Safe Energy Resources, TIT- Tokyo, Elsevier, (1992).

[9] H. Sekimoto and Zaki S. , Design Study of Lead and Lead-bismuth Cooled Small Long-life Nuclear Power Reactors Using Metallic and Nitride Fuel, Nuclear Technology, Vol. 105, no. 3 (1995), pp.307-313.

DOI: 10.13182/nt109-307

[10] Zaki Su'ud and H. Sekimoto : Design and Safety Aspect of Lead and Lead Bismuth Cooled Long-Life Small-safe Fast Reactor for Various Core Configuration, Journal of Nuclear Science and Technology Vol. 32 no. 9 (1995), pp.834-845.

DOI: 10.1080/18811248.1995.9731785

[11] Su'ud, Z. and H. Sekimoto, Preliminary Design Study of the Ultra Long Life Fast Reactor', Nuclear Engineering and Design, Vol. 140, 1993, pp.251-260.

DOI: 10.1016/0029-5493(93)90079-o

[12] Su'ud, Z. and H. Sekimoto, Design and Safety Aspect of Lead and Lead Bismuth Cooled Long-Life Small-safe Fast Reactor for Various Core Configuration, 1995, Journal of Nuclear Science and Technology 32 (9), pp.834-845.

DOI: 10.1080/18811248.1995.9731785

[13] Sekimoto, H. et al. (2001) CANDLE: The New Burn-up Strategy, Nuclear Science and Engineering, 139, pp.1-12.

[14] Sekimoto, H. and S. Miyashita (2005) Startup of CANDLE Burnup in Fast Reactor from Enriched Uranium Core, Proc. of 12th Conf. on Emerging Nuclear Energy System (ICENES 2005), Aug. 21-26, 2005, SCK. CEN, Mol., Brussels, Belgium.

DOI: 10.1016/j.enconman.2006.02.007

[15] Rida SNM and Z. Su'ud (2009) Design Study of Pb-Bi Cooled Fast Reactors Which Fuel Cycle Input is Natural Uranium, International Journal of Nuclear Energy Science and Technology Vol. 4 No. 3, pp.217-222.

DOI: 10.1504/ijnest.2009.027042

[16] Keisuke OKUMURA, Teruhiko KUGO, Kunio KANEKO and Keichiro TSUCHIHASHI, SRAC (Ver. 2002) ; The comprehensive neutronics calculation code system, JAERI Report, (2002).

[17] Nakagawa, M. and Tsuchihashi, K. , SLAROM: A Code for Cell Homogenization Clculation of Fast Reactor, JAERI M 1294, (1984).

[18] Z. Su'ud, FI-ITB CH1 code manual, internal report.
