Research on TZSI Control Method

Abstract:

In transformer-Z-source inverters (TZSI), the impedance networks consist of a transformer and one capacitor. While maintaining the main features of traditional Z-source network, the new networks exhibit some unique advantages, such as the increased voltage gain and reduced voltage stress in the voltage-fed TZSI, when the turns ratio of the transformer windings is over 1. This paper contributes to the ac small signal modeling and analysis of TZSI in continuous conduction mode. The ac small signal model considers the dynamics introduced by network uniquely contained in TZSI. And a double loop control method which is impedance source network output dc voltage and current loop has been proposed to realize the control of TZSI. Results of simulations and experiments are used to validate the control method and show that this method is correct and feasible.

• Periodical: Advanced Materials Research (Volume 773)
• Pages: 51-57
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.773.51
• Online since: September 2013
• Authors: Lei Pan, He Xu Sun, Lan Fang Fu, Bin Liu, Ran Gao, Bei Bei Wang
• Keywords: AC Small Signal Model, Double Loop Control, Impedance Source Network, TZSI

References

[1] Wei Qian, Fangzheng Peng, Honnyong Cha. Trans-Z-Source Inverters. IEEE Transactions on Power Electronics, 2011, 26(12): 3453-3463.

DOI: 10.1109/tpel.2011.2122309

[2] Cai Chunwei, Qu Yanbin, Sheng Kuang. Improved maximum constant boost control of Z-source inverter[J]. Electric Machines and Control, 2011, 15(12): 14-20.

[3] Zhang Chaohua, Tang Yu, Xie Shaojun. Third harmonic injection control strategy of improved Z-source inverter. Transactions of China Electro technical Society, 2009, 24(11): 114-119.

DOI: 10.1109/ecce.2009.5316222

[4] Tang Yu，Xie Shaojun，Zhang Chaohua． Improved Z-source inverter. Proceedings of CSEE, 2009, 24(11): 114-119.

DOI: 10.1109/ecce.2009.5316223

[5] Cheng Ruqi，Zhao Gengshen，Guo Tianyong． State feedback control strategy of Z-source inverter. Electric Machines and Control，2009, 13(5): 673-678.

DOI: 10.1109/peits.2009.5406811

[6] Cai Chunwei, Qu Yanbin, Sheng Kuang. Transient modeling and analysis of quasi-Z- source-inverter. Electric Machines and Control, 2011, 15(10): 7-13.

[7] M. H. Zhang, C. L. Xia, Y. Tian, et al. Speed control of brushless DC motor based on single neuron PID and wavelet neural network. Proc. IEEE Control Autom. Conf., 2007: 617- 620.

DOI: 10.1109/icca.2007.4376429

[8] G. C. Goodwin, S. F. Graebe, M. E. Salgado. Control System Design [M]. Upper Saddle River, NJ: Prentice-Hall, 2001: 201-205.

[9] Ho W. -H., Tsai J. -T., Chou J. -H. Robust-stable and quadratic- optimal control for TS-fuzzy-model- based control systems with elemental parametric uncertainties. Control Theory & Applications, IET. 2007, 1(3): 731 – 742.

DOI: 10.1049/iet-cta:20060159
