Analysis of Settlement Caused by Tunnel Underneath Existing Railway after Construction

Abstract:

For the existing railway, the settlement after construction caused by the tunnel underneath it is completed after the tunnel has been constructed. It is the result that the stress adjustment and consolidation of soil enhanced itself under the live load of train. Through the settlement can be calculated by peck formula in the stage of and after construction, for the settlement after construction, the peck formula must be transformed with the fitting monitoring curve. With the engineering example, the fitting formula of settlement after construction can be used for analysis and prediction of similar engineering.

• Periodical: Advanced Materials Research (Volumes 779-780)
• Pages: 534-537
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.779-780.534
• Online since: September 2013
• Authors: Ze Pei Xu, Xi Bing Li
• Keywords: Peck Formula, Settlement after Construction, Tunnel Underneath Railway

References

[1] Wang Zhi, Du Shouji, Zhang Wenbo, Li Yingjiu, Wu Xueping. Analysis of Construction Settlement of Shallow Railway Tunnel under Crossing the Highway. Chinese Journal of Underground Space and Engineering, (2009), (03): 531-535+572. [in Chinese].

[2] Ji Daxue. Analysis of the Influence of Underpass Shield of Wuhan Yangtze River Tunnel on Settlement of Wuhan-Jiujiang Railway. Journal of Railway Engineering, (2009), (10): 59-63. [in Chinese].

[3] Xu Gancheng, Li Chengxue, Queen of Yu, Zhao month, Hu Ping. Analysis of influence of metro shield tunneling crossing underneath high speed railway. Rock and Soil Mechanics, (2009), (S2): 269-272+276. [in Chinese].

[4] Xu Youjun, Tao Lianjin, Li Wenbo, Fan Junyi, Wang Wenpei. Numerical Simulation Study on the Settlement Laws of the High-speed Railway's Subgrade Induced by the Construction of Twin Shield Tunnel. Journal of Beijing University of Technology, (2010).

[5] Lou Guochong. Study on the Settlement and Controlling Criteria of Existing Embankment during Railway Tunnel Construction Under passing by Conventional Method. Beijing Jiaotong University, (2012). [in Chinese].

[6] Zheng Junjie, Bao Deyong, Gong Yanfeng, Zi Yi. Research on Construction Control Technology for Railway Tunnel Underneath Passing Existing Expressway Tunnel. Journal of Railway Engineering Society, (2006), (08): 80-84. [in Chinese].

[7] Lv Peilin Zhou Shunhua. Analysis on Upper Rail Settlement in Soft Ground Resulting from Shield Tunnelling across Main Railway Line. China Railway Science, 2007, (02): 12-16. [in Chinese].

[8] Wang Mingxiao. Wearing Dark Tunnel under Railway Transportation Line Designed Settlement. Journal of Dalian University, (2010), (06): 68-71. [in Chinese].

[9] Zheng Yuzhao, Qiu Wenge, Zhang Junru. Ground Displacement Caused by Three Pipes Shield-Driven Tunnels Through below Railway on the Ground and Control Technology. China Railway Science, (2007), (05): 65-70. [in Chinese].

[10] Han Xuan, lining, J.R. Standing. An adaptability study of Gaussian equation applied to predicting ground settlements induced by tunneling in China. Rock and Soil Mechanics, (2007), (01): 23-28+35. [in Chinese].

[11] Song Kezhi, Wang Mengshu, Sun Mou. Reliability Analysis of Ground Settlement with Shield Tunnel Construction Based on Peck Formula. Journal of Northern Jiaotong University, (2004), (04): 30-33. [in Chinese].

[12] Yao Aijun, Zhao Qiang, Guan Jiang Liu Fangyuan, Su Ning. Improvement of Peck Formula in Subway Construction in Beijing. Chinese Journal of Underground Space and Engineering, (2010), (04): 789-793. [in Chinese].

[13] Yang Qingyuan, Ma Feng Hai, Hu Guodong, Guo Xunjie. Improvement of Peck formula in subway construction under typical geological conditions. Journal of Liaoning Technical University(Natural Science), (2012), (02): 159-162. [in Chinese].
