Study on Tension Model of Running Deviation for Strip Rolling

Abstract:

For running deviation of strip and camber deviation, a tension model was established on the discussion of the dynamic equilibrium state under tension. The friction difference of strips sides or workpiece wedge causes plain rolling camber, meanwhile housings elasticity inequality or roll tilt leads to axial shifting and camber deviation. In the digital simulation, the tension-drawing model is necessary to realize tension self-adjusting, and in the production, tension increments can be calculated for adjusting the two sides gaps.

• Periodical: Advanced Materials Research (Volumes 779-780)
• Pages: 84-87
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.779-780.84
• Online since: September 2013
• Authors: Shen Bai Zheng, Xin Zhou Huo, Jin Zhi Yin, Gai Yan Yang, Wei Zhang
• Keywords: Center Excursion, Deviation of Strip, Rolling Simulation, Sickle Bent, Tension Drawing

References

[1] Yubo Zheng, Guangyao Xiao, Changrui Zheng, et al. The Analysis of Ultra-Thin Strip Running-off in Tangshan Steel and Some Correcting. Standard and Quality of Metallurgy, 2007, 45(1): 24-27. (In Chinese).

[2] Xiaoli Dai, Xianming Zhao, Guodong Wang. Dynamic Simulation on Serpentine Process of Hot Rolled Strip. Steel Rolling, 2003, 20(2): 4-7. (In Chinese).

[3] Jiangang Zhou, Zhong Xu, XiaoBo Wang, et al. System Simulation of Baosteel 2030 Tandem Cold Rolling. Metallurgical automation. 2003, 27(5): 5-8. (In Chinese).

[4] Kezhi Linhu，Yang Wang，Guangming Liu，Jianjun Qiao. Model of Relationship between Wedge and Running-off of Strip during Colding. Steel rolling, 2012, 29(1): 22-24. (In Chinese).

[5] Shiraishi T, Hibata, Mizuta A, et al, Relation between Camber and Wedge in Flat Rolling under Restrictions of Lateral Movement. ISIJ Internation, 1991, 31(6): 583-587.

DOI: 10.2355/isijinternational.31.583

[6] Xiaochong Wang. Study on Running-off and the Best Tension law in Hot Continuous Rolling Aluminium . Central South University, 2008. (In Chinese).
