Temperature Distribution and Polarization Curve Sensitivity in the Proton Exchange Membrane Fuel Cell Single Cell

Abstract:

This work is a study of coupled charges and heat transfers phenomena on a low temperature PEMFC single cell. A one-dimensional steady state model was developed to compute current and temperature distributions in a PEMFC single cell whatever the operating conditions. The work comprises of three parts: Firstly, a litterature survey was conducted to describe the principle of a PEMFC and the fundamental operations. A state of the art of the previous modeling works on the PEMFC was also presented in this part. Secondly, the developed model using the basic relations to describe heat and charges transfer phenomena occurring in the single PEM cell was presented. Finally , a simple simulation tool called FCvb was performed and optimized using Visual Basic Excel and refering to the previous relations in the developed model. To finalize this basic study, a conclusion and perspectives were presented in the last part of this work.

• Periodical: Advanced Materials Research (Volume 787)
• Pages: 655-660
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.787.655
• Online since: September 2013
• Authors: B. Khelidj, B. Abderezzak, M. Tahar Abbes, A. Kellaci
• Keywords: Charge Transfer, Heat Transfer, Modelling Tool, Polarization Curve, Polymer Electrolyte Membrane Fuel Cells

References

[1] Zhang L., Wang N., 2013, An adaptive RNA genetic algorithm for modeling of proton exchange membrane fuel cells, Int. J. Hydrogen Energy, vol. 38, n°1 : p.219 – 228.

DOI: 10.1016/j.ijhydene.2012.10.026

[2] Kunusch C., Puleston P. F., Mayosky M. A., More´ J. J., 2010, Characterization and Experimental Results in PEM Fuel Cell Electrical Behavior, Int. J. Hydrogen Energy, Vol. 35, n°1 : pp.5876-5881.

DOI: 10.1016/j.ijhydene.2009.12.123

[3] Latha K., Vidhya S., Umamaheswari B., Rajalakshmi N., Dhathathreyan KS., 2013, Tuning of PEM Fuel Cell Model Parameters for Prediction of Steady State and Dynamic Performance Under Various Operating Conditions, Int. J. Hydrogen Energy, Vol. 38, n°5: p.2370.

DOI: 10.1016/j.ijhydene.2012.11.102

[4] Blunier B., Miraoui A., Piles à Combustible, 2007, ellipses editions Technosup Génie Energétique, 1st ed., Paris.

[5] Peraza C., Diaz J.G.,  Arteaga-Bravo F.J., Villanueva C., Gonzalez-Longatt F., 2008, Modeling and Simulation of PEM Fuel Cell with Bond Graph and 20sim, IEEE Xplore American Control Conference: p.5104 – 5108.

DOI: 10.1109/acc.2008.4587303

[6] Husar A., Strahl S., Riera J., 2012, Experimental Characterization Methodology for the Identification of Voltage Losses of PEMFC: Applied to an Open Cathode Stack, Int. J. Hydrogen Energy, Vol. 37, n°1: p.7309 – 7315.

DOI: 10.1016/j.ijhydene.2011.11.130

[7] Hinaje M., Nguyen DA., Bonnet C., Lapicque F., Raël S., Davat B., 2011, 2D Modeling of a Defective PEMFC, Int. J. Hydrogen Energy, Vol. 36, n°1: p.10884 – 10890.

DOI: 10.1016/j.ijhydene.2011.05.146

[8] Laurencelle F., Chahine R., Hamelin J., 2001, Characterization of a Ballard (MK5-E) Proton Exchange Membrane Fuel Cell Stack, Fuel Cells, Vol. 1, n°1: p.66 – 71.

DOI: 10.1002/1615-6854(200105)1:1<66::aid-fuce66>3.0.co;2-3

[9] Gloaguen F., Convert P., Gamburzev S., Velev O.A., Srinivasan S., 1998, An Evaluation of the Macro-Homogeneous and Agglomerate Model for Oxygen Reduction in PEMFCs, Electrochim. Acta, Vol. 43, n° 24: p.3767–3772.

DOI: 10.1016/s0013-4686(98)00136-4

[10] Ramousse J., Deseure J., Lottin O., Didierjean S., Maillet D., 2005, Modelling of Heat, Mass and Charge Transfer in a PEMFC Single Cell, J. Power Sources, Vol. 145, n°1: p.416 – 427.

DOI: 10.1016/j.jpowsour.2005.01.067

[11] Chupin S., Colinart T., Didierjean S., Dubé Y., Agbossou K., Maranzana G., Lottin O., 2010, Numerical Investigation of the Impact of Gas and Cooling Flow Configurations on Current and Water Distributions in a Polymer Membrane Fuel Cell Through a Pseudo-Two-Dimensional Diphasic Model, J. Power Sources, Vol. 195, n°1 : p.5213.

DOI: 10.1016/j.jpowsour.2010.03.027

[12] Incropera F. P., De Witt D. P., Bergman T. L., Lavine A. S., Fundamentals of Heat and Mass Transfer, 2007, John Wiley & Sons, 6th ed., Indiana, USA.
