Deformation Behaviour of Silicon Carbide Reinforced Al-7Si Composite after Balistic Impacts

Abstract:

The deformation after ballistic impact loading of silicon carbide reinforced aluminium alloy composite is investigated in this research. The composite consists of 10 % volume fraction of silicon carbide particulate in a matrix of Al-7Si-Mg-Zn alloy and were produced through the squeeze casting process with a pressure of 1 MPa at semi-solid melting temperatures of 590-610 °C. The mechanical property of the composite was examined with hardness test. The ballistic tests were performed with two types of projectiles, 9 mm and 5.56 mm calibre of projectiles. Furthermore the deformed surfaces were studied with optical microscopy. During ballistic testing, the 9 mm projectile did not pierce the composite plate although the test resulted in significant cracks on the backside of the plate. The cross section observation of the plate showed ductile deformation in the matrix and silicon carbide particulates give significant rule in withstanding the penetration of the projectile. By contrast, the 5.56 mm projectile pierced through the composite and caused a brittle fracture of the matrix.

• Periodical: Advanced Materials Research (Volume 789)
• Pages: 33-36
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.789.33
• Online since: September 2013
• Authors: Bondan Tiara Sofyan, Dwi Rahmalina, Bambang Suharno, Eddy S. Siradj
• Keywords: Aluminum Composite, Armour Material, Ballistic Impact, Deformation, Silicone Carbide

References

[1] B. Srivatsa, N. Ramakrishnan: On The Ballistic Performance of The Metallic Materials, Bulletin of Material Science, Vol. 20, no. 1, (1997), pp.111-123.

[2] S. Chabba, M. van Klinken, E.J. Jongedijk, M.J. Vanek, D. Gijsman, P. van der Walls, A.C.L. MAccelerated Aging Study of Ultra High Moleculer Weight Polyethylene Yarn and Unidirectional Composites for Ballistic Applications, Journal of Material Science, 42, (2007).

DOI: 10.1007/s10853-007-1617-7

[3] T. Lin, Q. Yang, C. Tan, B. Liu, A. McDonald, Processing and Ballistic Performance of Lightweight Armor Based on Ultra-fine-grain Aluminum Composites, Journal of Materials Science, 43, (2008), pp.7344-7348.

DOI: 10.1007/s10853-008-2977-3

[4] M.B. Karamis, F. Nair, A.A. Cerit, The Metallurgical and Deformation Behaviours of Laminar Metal Matrix Composites after Ballistic Impact, Journal of Materials Processing Technology, 209, (2009). 4880-4889.

DOI: 10.1016/j.jmatprotec.2009.01.008

[5] T. Demir, M. Ubeyli, R.O. Yildirim, Investigation on Ballistic Impact Behavior of Various Alloy against 7. 52 mm Armor Piercing Projectile, Materials and Design, 29, 10, (2008), p.2009-(2016).

DOI: 10.1016/j.matdes.2008.04.010

[6] M.J. Forrestal, T.L. Warren, Perforation Equations for Conical and Ogival Nose Rigid Projectiles into Aluminum Target Plates, Intenational Journal of Impact Engineering, 36, 2, (2009), pp.220-225.

DOI: 10.1016/j.ijimpeng.2008.04.005

[7] A.L. Dons, G. Heiberg, J. Voje, J.S. Mӕland, A. Prestmo, On the Effect of Additions of Cu and Mg on the Ductillity of AlSi Foundry Alloy Cast with A Cooling Rate of Approximately 3 K/s, Materials Science and Engineering A 413-414, (2005).

DOI: 10.1016/j.msea.2005.09.053

[8] D. Rahmalina, B.T. Sofyan, B. Suharno, E.S. Siradj, Development of Steel Wire Rope-Reinforced Aluminium Composite for Armour Material Using The Squeeze Casting Process, Advanced Materials Research Journal, Vol. 277, (2011), pp.27-35.

DOI: 10.4028/www.scientific.net/amr.277.27

[9] B.T. Sofyan, S. Susanti, R.R. Yusfranto, Peran 1 dan 9 w. t. % Zn dalam Proses Pengerasan Presipitasi Paduan Aluminium AA319, Makara, Teknologi, 12, 1, (2008), 48-54.

DOI: 10.7454/mst.v12i1.523

[10] Ballistic Resistance of Body Armor NIJ Standard-0101. 05, U.S. Department of Justice, (2008).
