Analysis of Crack Patterns of 500MPa Reinforced Concrete Beams

Abstract:

Fourting concrete beams reinforced with 500MPa longitudinal steel bars, of which 6 with skin reinforcement and 8 without skin reinforcement, were tested under two-point symmetrical concentrated static loading to investigate their crack patterns. Crack distributions in constant moment region of beams are compared. The propagation of side cracks along the beam depth is obtained. The results of this study indicate that the concrete cover of longitudinal tensile steel bars and the spacing of skin reinforcement has significant effect on crack distributions; substantial crack control in beams can be achieved if the spacing of skin reinforcement is limited to certain critical values. The curve of d-w(d is the distance between observation points of side cracks and tension face of beams, w refers to crack width at observation points) is approximately characterized by a zig-zag shape and concave-left near longitudinal tensile steel bars.

• Periodical: Advanced Materials Research (Volume 790)
• Pages: 120-124
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.790.120
• Online since: September 2013
• Authors: Zhi Hua Li, Xiao Zu Su
• Keywords: Crack Pattern, High-Strength Bar, Reinforced Concrete (RC) Beam, Skin Reinforcement

References

[1] Standards China. (1998). Hot ribbed bar of reinforced concrete(GBl499-1998). Beijing: China Building Industry Press. (In Chinese).

[2] Standards China. (2010). Code for design of concrete structures (GB50010-2010). Beijing: China Building Industry Press. (In Chinese).

[3] Jiwei Zhang, Wenjie Ge, Huang Dai, Yongming Tu. Experimental study on the flexural behavior of concrete beam reinforced with HRBF500 steel bars. Advanced Material Research, Vol. 168-170 (2011), pp.1518-1523.

DOI: 10.4028/www.scientific.net/amr.168-170.1518

[4] Ting Zhang. (2004). Experimental research on the performance of flexural members reinforced with 500MPa steel bars. MSc thesis, Zhengzhou University. (In Chinese).

[5] Jinjie Zhao. (2008). Experimental investigation of flexural performance of concrete beams with HRBF500 bars. MSc thesis, Beijing Industrial University. (In Chinese).

[6] Tiecheng Wang, Yanyan Li, Xian Rong. Test for bending behavior of reinforced concrete beam with 500Mpa steel bar. Journal of Tian Jin University, Vol. 40 (2007), pp.507-511. (In Chinese).

[7] Qiong Li. (2009). Experimental and theoretical study on crack widths of full scale reinforced concrete beams with HRB500 Bars. MSc thesis, Hunan University. (In Chinese).

[8] Mingping Wang, Ziqiong Zhang, Shujiang Geng. Experimental of reinforced concrete simply supported beam with 500Mpa ribbed carbon bars under bending. Industrial Building, Vol. 37 (2007), pp.39-42. (In Chinese).

[9] Fei Chen. (2009). Experimental research on the short-time crack width formulae of concrete beams reinforced with 500MPa steel bars. MSc thesis, Tongji University. (In Chinese).

[10] Junfeng Guan, Shunbo Zhao, Chengkui Huang. Experimental study on regularity of crack elongation hight in reinforced concrete beams. Journal of base science and engineering, Vol. 19(2011), pp.118-259. (In Chinese).

[11] Maomao Du, Xiaozu Su. Analysis of crack patterns of post-tensioned bonded prestressed concrete beams with 500Mpa steel bars. Journal of Shengyan Jianzhu University, Vol. 28 (2012), pp.796-802. (In Chinese).
