Analysis on In-Plane and Out-Plane Instability Coupling of Steel Bowstring Arch Bridge with Box Section Single Rib

Abstract:

Steel single rib box section arch bridge is established on the basis of secondary development using parametric language of large-scale finite element software ANSYS. On the premise of same sectional area A of arch rib,height breadth ratio h/b is changed, and both the spatial instability mode under the condition of arch bridges dead weight and the stability safety coefficient under the condition of the first step instability mode is calculated. With the aim to optimize distribution of stiffness and stability of single rib arch bridge, the target is to find out a height breadth ratio h/b which can make in-plane and out-plane instability mode coupling, that is to say, equivalent stiffness of in-plane and out-plane of the mode.

• Periodical: Advanced Materials Research (Volume 790)
• Pages: 337-340
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.790.337
• Online since: September 2013
• Authors: Xing Rui Wang, Ji Kai Jin, Gang Yang
• Keywords: ANSYS, Bending Stiffness, Instability Mode, Safety Coefficient, Steel Single Rib Box Section Arch Bridge

References

[1] Xu Junlan. Steel Bridge. Beijing: China Communications Press. (2011).

[2] Brandon Lee. Stability and vibration of Bridge Structures. China Railway Publishing House.

[3] General Specification for Design of Highway Bridges and Culverts JTG D60-2004. Beijing: Highway Planning and Design Institute. (2004).

[4] Jianmin Zhang, Cheng even, Qin Rong. Study on Stability of Arch Bridge. Guangxi Communication Science and Technology, 2000, 25 (4).

[5] Timosenko S P. Elasticity Stability Theory [M]. Beijing: Sciences Publishing House, (1958).
