The Hardware Design and Implement of an Image Information Collection System

Abstract:

It introduces the hardware design and implement of the image information collection system which is one part of Fluorescent magnetic particle nondestructive detection system of Cannonball. The image information collection system includes Open collecting card model Initialize collection card modelApply for EMS memory modelCollecting image modelWrite bitmap information head model Show pictures modeClose collection card model. Through collecting image information to the EMS memory and then processing the image information, the magnetic images on the cannonball are showed clearly on computer, and cracks on the cannonball can easily to be judged. The software of the image information collection system is developed by Visual C++.

• Periodical: Advanced Materials Research (Volume 804)
• Pages: 211-215
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.804.211
• Online since: September 2013
• Authors: Feng Ying Guo
• Keywords: Collection, Hardware Design, Implement, Mage Information, Visual C++
