Comparison of Photoacoustic Behaviors between Helmholtz Cell and its Remodified One

Abstract:

This paper presents method and performance of the Helmholtz photoacoustic resonant cell and its remodified one which both were designed and tested respectively based on the measurement of the CO₂ contribution of the photoacoustic signal in experiments. The average optical power at the laser operating point was 800mW for the10.653um laser (CO₂ detection). On-line and real time measurement CO₂/N₂ mixtures (CO₂ 300ppm) were then performed. The Helmholtz photoacoustic resonant cell and its remodified one test of the carbodioxide conducted at their respective resonant frequency demonstrated signals about 43mV and 67mV, signal-to-noise (S/N) values about 47dB and 51dB respectively. According to test results, the remodified one also has a better quality factor. All this demonstrate the remodified Helmholtz cell can preferably improve excitation of acoustical signal.

• Periodical: Advanced Materials Research (Volume 804)
• Pages: 251-255
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.804.251
• Online since: September 2013
• Authors: Jun Juan Zhao, Xian Hui Li, Wei Zhang, Zhan Zhao
• Keywords: Gas Detection, Helmholtz, Photoacoustic, Spectroscopy

References

[1] David A. Heaps and Paul M. Pellegrino: Examination of Quantum Cascade Laser Source for a MEMSscale Photoacoustic Chemical Sensor, Proc. of SPIE Vol. 6218 (2006) 621805.

[2] Paul M. Pellegrino and Ronald G. Polcawieh: Advancement of a MEMS photoacoustic Chemical Sensor, Proc. OfSPIE. 5085(2003)52-63.

[3] K. Schjølberg-Henriksen, D.T. Wang, H. Rogne: High-resolution pressure sensor for photo acoustic gas detection, Sensors and Actuators A, 132 (2006) 207–213.

DOI: 10.1016/j.sna.2006.02.019

[4] Carmen Hernandez, Todd Murray, Sridhar Krishnaswamy: Characterization of Thin Film MEMS Using Photo-acoustic Microscopy, Department of Mechanical Engineering Northwestern University.

[5] S.L. Firebaugh, K.F. Jensen, and M.A. Schmidt: Miniaturization and Integration of Photoacoustic Detection with a Microfabricated Chemical Reactor System, JMEMS, 10(2001) 232-237.

DOI: 10.1109/84.925756

[6] S.L. Firebaugh, K.F. Jensen, and M.A. Schmidt: Miniaturization and integration of photoacoustic detection, J. Appl. Phys. 92(2002) 1555-1563.

DOI: 10.1063/1.1489493

[7] Nils C. Fernelius, Helmholtz resonance effect in photoacoustic cell, Appl. Opt. 18(1979) 1784 -1787.

DOI: 10.1364/ao.18.001784

[8] V. Zéninari, B. Parvitte, D. Courtois, V. Kapitanov, and Y. Ponomarev, Methane detection on the sub-ppm level with a near-infrared diode laser photoacoustic sensor, Infrared Phys. Technol. 44 (2003) 253-261.

DOI: 10.1016/s1350-4495(03)00135-x

[9] G. Busse and D. Herboeck, Differential Helmholtz resonator as an optoacoustic detector, Appl. Opt. 18(1979)3959-3961.

DOI: 10.1364/ao.18.003959

[10] V. Zéninari, V. Kapitanov, D. Courtois, and Y. Ponomarev, Design and characteristics of a differential Helmholtz resonant photoacoustic cell for infrared gas detection, Infrared Phys. Technol. 40(1999) 1-23.

DOI: 10.1016/s1350-4495(98)00038-3
