Behavior Analysis of the DFIG Wind Turbine in Voltage Double-Dip

Abstract:

At present, the research on wind turbine low voltage ride through (LVRT) behavior is one of hotspots in wind power industry. With increasing share of wind power in the grid, it is important to enhance the LVRT performance of wind turbines to guarantee the safety and reliability of the grid. The phenomenon of voltage double-dip is one of cases during the voltage dips. In this paper, the voltage double-dip phenomenon is described, and the stator flux attenuation of DFIG wind turbine in the voltage dip is analyzed. The results show that when the second voltage dip occurs, the initial value of the stator flux should be considered. Finally, by on-site testing results, the impact of voltage double-dip to the wind turbine is verified, if the initial value of the stator flux is not considered, and the interval of two voltage dips is different.

• Periodical: Advanced Materials Research (Volumes 805-806)
• Pages: 382-386
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.805-806.382
• Online since: September 2013
• Authors: Yong Sun, Chen Chen, Rui Ming Wang, Shao Lin Li, Jin Ping Zhang
• Keywords: Double Fed Induction Generation (DFIG), Low Voltage Ride through (LVRT), Voltage Double-Dip, Wind Turbine (WT)

References

[1] GUAN Hong-liang，ZHAO Hai-xiang. Requirement for LVRT Capability of Wind Turbine Generator in Power System [J]. Power System Technology, 2007, 3l(7): 78-82.

[2] LI Shao-lin, LI Qing, TAN Li-hua. Power Balance Control of Wind Turbine Converter Under Voltage Sag in Power Grid [J]. Power System Technology, 2011, 35(6): 149-154.

[3] Wind Turbines Connected to Grids with Voltages above 100 kV. Technical regulation for the properties and the regulation of wind turbines [S]. (2004).

[4] Johan Morren, and Sjoerd W.H. de Haan. Ride through of wind turbines with doubly-fed induction generator during a voltage dip. IEEE Trans. Energy Conversion, pp.435-441, vol. 20, Jun. (2005).

DOI: 10.1109/tec.2005.845526

[5] YANG Shu-ying. Converter and Control for Doubly Fed Induction Generator-Based Wind Power Generation [D]. Hefei University of Technology, (2007).

[6] ZHANG Xue-guang, XU Dian-guo. Research on control of DFIG with active crowbar under symmetry voltage fault condition [J]. Electric Machines and Control, 2009, 13(1): 99-103.

[7] Morren J, Haan S W H. Ride through of wind turbines with doubly-fed induction generator during a voltage dip [J]. IEEE Trans on Energy Conversion, 2005, 20(2): 435-441.

DOI: 10.1109/tec.2005.845526
