Calculation of Coach Body Heat Transfer Coefficient for the High-Speed Railway Train in China

Abstract:

The coach body of the high-speed railway train is required to have a good thermal insulation performance. It can keep a comfort passenger environment and decrease demand for the cooling load of air-conditioning system. The determination of coach body heat transfer coefficient (K-value) is critical for the efficient design of vehicle air-conditioning system. A heat transfer coefficient calculation model is especially proposed for the typical aluminum section thermal insulating wall structure of high-speed trains coach body in china, on the basis of the fin heat transfer mechanism. For the train type of CRH3G, the calculating coach body heat transfer coefficient is in good agreement with the experimental value. So the proposed calculation method can significantly improve the computational efficiency of the K-value for the high-speed railway trains which have the typical aluminum section insulation wall structures, and provide a trustable basis for the coach body structure optimization design.

References

[1] Raghu S. Raghunathan, H. -D. Kim, etc. Aerodynamics of high-speed railway train [J]. Progress in Aerospace Sciences 38 (2002) 469-514.

DOI: 10.1016/s0376-0421(02)00029-5

[2] A. Mezrhab, M. Bouzidi. Computation of thermal comfort inside a passenger car compartment [J]. Applied Thermal Engineering 26 (2006) 1697–1704.

DOI: 10.1016/j.applthermaleng.2005.11.008

[3] Niu De-tain. Application of Al alloy carbody to railway vehicles and its prospects[J]. Locomotive and Rolling Stock Technology, 2003, 6. (In Chinese).

[4] Li Li, Jing June, Jiang Yunhai. Optimization Calculation of K Value of Train Based on Cold Bridge Analysis[J]. Journal of Qingdao technological university, 2010, 31(2): 63-68. (In Chinese).

[5] Du Zixue, Yuchi Zhipeng, Liu Jianxun. Calculation of Heat Transfer Coefficient for Insulation Wall of Straddle-type Monorail Vehicle[J]. Study on the City Rail Transit, 2011, 4. (In Chinese).

[6] Xu Jun, Cai Mingwei, LiuYedi. Simulation Calculation of Heat Transfer Coefficient of High-speed Train[J]. Railway Vehicles, 2011, 12. (In Chinese).

[7] Liu Yingqing, Cai Deyuan, Lu Daqing. Exploratry Investigation on Methods for Calculating Heat-transfer Coefficient of Passenger Car Body[J]. SouthWest Jiao Tong University. 1985, 9. (In Chinese).

[8] Zhang Yin. Vehicle Design Reference Manual[M]. beijing: China Railway Press. 2003. (In Chinese).

[9] Gan Xia, Sheng Sisi, Sun Baohong. The Calculation Method of Heat Insulation Wall Heat Transfer Coefficient and Its Improvement[J]. Refrigeration and Air Conditioning. 2012, 12. (In Chinese).
