Power Characteristics of Photovoltaic Modules of Solar-Powered Airplanes Including Thermal Effects

Abstract:

A power characteristic model of photovoltaic (PV) modules on the wing of solar-powered airplanes operated from sea level to the stratosphere is established. Because the efficiency of PV modules is a function of surface temperature, the proposed model includes thermodynamic effects. Firstly, the real-time power characteristics are analyzed at the altitudes of 10 km and 30 km and during the summer and winter solstice. Then, further investigations are conducted to research the daily averaged power per unit area from 0 km to 35 km throughout a whole year. The results show that the low atmosphere temperature is favorable condition for PV modules to obtain high absorption efficiency, and total solar radiation increases with the altitude increasing. However, the thinness of atmosphere density at high altitudes leads the deduction of Reynolds number, resulting in less heat carried away and the efficiency deterioration of PV modules. The maximum power collected occurs around 11 km. The research work shows that it is necessary to take into consideration the thermal effects on the efficiency of PV modules at high altitudes.

• Periodical: Advanced Materials Research (Volumes 805-806)
• Pages: 58-62
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.805-806.58
• Online since: September 2013
• Authors: Min Chang, Zhou Zhou*, Rui Wang
• Keywords: Efficiency, Operating Altitude, Photovoltaic Modules, Power Characteristic, Solar-Powered Airplane, Surface Temperature, Temperature Coefficient

References

[1] Min Chang, Zhou Zhou, Yingying Li. An Effective Theoretical Analysis of Persistent Flight Altitudes of Solar-Powered Airplanes[J]. Journal of Northwestern Polytechnical University, 2012, 30(4): 541-546.

[2] Terry D. Haws, W. Jerry Bowman, Thermal Analysis of the Pathfinder Aircraft [R]. AIAA 99-0735, (1999).

[3] Xiaojian Li, Xiande Fang, Qiuming Dai. Research on Thermal Characteristics of Photovoltaic Array of Stratospheric Airship[J]. JOURNAL OF AIRCRAFT, 2011, 48(4): 1380-1386.

DOI: 10.2514/1.c031295

[4] B. Keidel, Auslegung und Simulation von Hochfliegenden Dauerhaft Stationierbaren Solardrohnen(Ph. D). München: Technischen Universität München Fakultät für Maschinenwesen, (2000).

[5] Durisch W., Urban J., Smestad G. Characterisation of Solar Cells and Modules Under Actual Operating Conditions[J]. Renewable Energy, 1996, 8(1-4): 359-366.

DOI: 10.1016/0960-1481(96)88878-1

[6] D.A. Scheiman, P.P. Jenkins, D.J. Brinker, J. Appelbaum, Low Intensity Low Temperature (LILT) Measurements and Coefficients on New Photovoltaic Structures[C]. Progress in Photovoltaics: Research and Applications, John Wiley and Sons, Inc., (1996).

DOI: 10.1002/(sici)1099-159x(199603/04)4:2<117::aid-pip123>3.0.co;2-c

[7] Incropera Frank P., David P. Dewitt, Fundamentals of Heat and Mass Transfer[M]. New York: John Wiley & Sons, (2011).

[8] André NOTH, Design of Solar Powered Airplanes for Continuous Flight(Ph. D). Switzerland: ETH ZÜRICH Ecole Polytechnique Fédérale de Lausanne, (2008).

DOI: 10.3940/rina.innovsail.2010.14
