Thermal Characteristics Analysis of Nuclear Power CNC Wheel Groove Milling Machine Based on Finite Element

Abstract:

For nuclear power CNC wheel groove milling machine in the work under the influence of a variety of heat sources, establish the finite element model of machine, using finite element analysis software ANSYS, analysis and thermal-structure coupling of heat source in the processing state mechanism, thermal key points out machine, the effect of deformation on the machine geometric accuracy evaluation of heat, and the machine thermal optimization analysis of corresponding, deformation of machine in the three direction. The results show that: the machine in machining spindle heat is an important factor affecting the machining accuracy of machine tools, and heat through various ways to machine tool bed, causing warping, guide rail bending, through this analysis provides reference for analysis and optimization design for the machine tool thermal deformation.

• Periodical: Advanced Materials Research (Volumes 816-817)
• Pages: 1100-1104
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.816-817.1100
• Online since: September 2013
• Authors: Zhi Wei Li, Dan Lu Song
• Keywords: Finite Element Analysis (FEA), Nuclear Power CNC Wheel Groove Milling Machine, Thermal Analysis, Thermal Deformation

References

[1] Yun W S, Kim S K, Cho D W. Thermal error analysis for a CNC lathe feed drive system [ J ] . International Journal of Machine Tools & Manufacture, 1998, 39 (1) : 1087 -1101.

DOI: 10.1016/s0890-6955(98)00073-x

[2] Guo Xuexiang. Machine tool feed system hot state characteristics of the numerical simulation study [D]. Wuhan: huazhong university of science and technology, (2007).

[3] Guo Xuexiang Hu Youmin, Xia Junyong, wu. Based on the finite element analysis of machine tool guideway thermal deformation research [J]. Modular machine tool and automatic processing technology, 2007, (3), 8-11.

[4] OkushimaK, Kakino Y. An analysis of methods used minimizing thermal deformations of machine tools[J]. 16thMT. DR, 1975, 16(10): 1012-1017.

[5] Venugopal R. Thermal effects on the accuracy of numerically controlled machine tool[J]. Annals of CIRP, 1986, 35(1): 80-92.

DOI: 10.1016/s0007-8506(07)61882-4

[6] Hong Yang, Jun Ni. Adaptive model estimation of machine tool thermal errors based on Recursive dynamic modeling strategy. Intemational Joumal of Machine Tools&Manufacture, 2005, 45(1): l-15.

DOI: 10.1016/j.ijmachtools.2004.06.023
