Rapid Reverse Modeling for a Boring Bar with Complex Surface

Abstract:

For some product development processes, reverse engineering (RE) allows to generate surface models by using the coordinate measuring machine (CMM) scanning technique, for this methodology permits to manufacture different tools in a short development period. A case study on a boring bar with complex surface is present for a brief overview of RE and provide benefits to improve the efficiency of designing and production processes. In order to guarantee the precision of the boring bar model, two methods of software Imageware for rule surface reconstruction and NURBS fitting are used. According to compare experimental modal data with simulation modal data, verified the viability of rapid reverse modeling for damping boring bar.
