Modeling Cutter Engagement Region for Triangular Mesh

Abstract:

Cutter Engagement Region (CER) is the part of tool that contacts with stock, where a series of energy exchange and material transportation take place. A full understanding of its shape and area is indispensible for cutting force calibration, chatter analysis, and tool wear prevention. It can provide a criterion for efficient tool-path planning as well. In literature, however, there is no available modeling of CER. We hereby propose a modeling method for ball-end tool with design surface represented in triangular mesh. First, design surface is offset to form a stock surface. Next, compute the intersection between every triangular facet and the tool. Then, connect all the intersecting arcs to form the boundary of CER. Finally, compute the area of CER. Experimental validation for the proposed method is still needed.

You might also be interested in these eBooks

Contemporary Design and Manufacturing Technology

View Preview

Info:

Periodical:

Advanced Materials Research (Volume 819)

Pages:

55-58

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.819.55

Citation:

Cite this paper

Online since:

September 2013

Authors:

Wen Feng Gan, Hong Yao Shen, Zhi Wei Lin, Zhi Yu Chen, Jian Zhong Fu

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] P. Lee, Y. Altintas, Prediction of ball-end milling forces from orthogonal cutting data, International Journal of Machine Tools & Manufacture, 36 (1996) 1059-1072.

DOI: 10.1016/0890-6955(95)00081-x

Google Scholar

[2] I. Lazoglu, Sculpture surface machining: a generalized model of ball-end milling force system, International Journal of Machine Tools & Manufacture, 43 (2003) 453-462.

DOI: 10.1016/s0890-6955(02)00302-4

Google Scholar

[3] A. Lamikiz, L.N.L. de Lacalle, J.A. Sanchez, M.A. Salgado, Cutting force estimation in sculptured surface milling, International Journal of Machine Tools & Manufacture, 44 (2004) 1511-1526.

DOI: 10.1016/j.ijmachtools.2004.05.004

Google Scholar

[4] Z. Li, W. Chen, A global cutter positioning method for multi-axis machining of sculptured surfaces, International Journal of Machine Tools & Manufacture, 46 (2006) 1428-1434.

DOI: 10.1016/j.ijmachtools.2005.10.006

Google Scholar
