A Combined Error Model for Thermal Error Compensation of Machine Tools

Abstract:

In this paper, a combined error model for thermal error compensation of machine tools is presented. Through the analysis of thermal error data of machine spindle at different temperatures, the error variation law is obtained. Experiments on the axial directional spindle deformation on a CNC machine center are conducted to build and validate the proposed models. The experimental validations show that the thermal errors of the machine tool are reduced effectively after applying the error compensation approach. The combined error model performs better than the traditional time series and neural network model in terms of prediction accuracy and robustness, which means that the new model is more suitable for complex working conditions in industrial applications.

• Periodical: Advanced Materials Research (Volume 820)
• Pages: 147-150
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.820.147
• Online since: September 2013
• Authors: Wei Wang, Jian Guo Yang
• Keywords: Error Compensation, Error Model, Machine Tool, Thermal Error

References

[1] W. K. Abdul and C Wuyi: Int. J. Adv. Manuf. Technol. Vol. 53 (2011), p.615.

[2] Y.X. Li, J.G. Yang, T. Gelvis and Y.Y. Li: Int. J. Adv. Manuf. Technol. Vol. 35 (2008), p.745.

[3] H. S. Choi and S. K. Lee: Mechatro. Vol. 12 (2002), p.643.

[4] J. H. Lee and S. H. Yang: Int. J. Mach. Tools Manuf. Vol. 42 (2002), p.147.

[5] J. M. Fines and A. Agah: Eng. Appl. Artif. Intel. Vol. 21 (2008), p.1013.

[6] J.H. Shen and J.G. Yang: Key Eng. Mater. Vol. 392 (2009), p.30.

[7] Y.X. Li and H.C. Tong: J. Sichuan Univ. Vol. 37 (2006), p.74.

[8] H. Yang and J. Ni: J. Manuf. Sci. Eng. Vol. 125 (2003), p.245.

[9] A. Kizilkaya and A.H. Kayran: J. Frankl. Inst. Vol. 342 (2005), p.39.
