Research on the Structural Performance of Large-Tonnage Gantry Crane

Abstract:

Because of the huge lifting weight and complex structure of large-tonnage gantry crane and in order to effectively design and review it, this paper aims to carry out a research on its structural performance based on the method of theoretical calculation and finite element analysis. During the early period of design, the method of theoretical calculations is adopted, and after specific design it comes the finite element analysis, so as to get the results of analysis under a variety of operating conditions, which illustrates that the structural design and review of large-tonnage gantry crane based on theoretical calculations and finite element are feasible, and also verifies that the method of finite element is an effective way to find a real dangerous cross-section, thus providing the basis for the design and manufacture of the crane structure.

• Periodical: Advanced Materials Research (Volume 823)
• Pages: 247-250
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.823.247
• Online since: October 2013
• Authors: Jie Dong, Wen Ming Cheng, Yang Zhi Ren, Yu Pu Wang
• Keywords: Finite Element, Gantry Crane, Structural Strength, Theoretical Calculation

References

[1] Z.W. Zhang, J.N. Wang: Crane Design Manual (China Railway Press, China 1998), pp.683-685. (In Chinese).

[2] J.N. Wang, L.F. Yu: Lifting Conveyor and Metal Structure (China Railway Press, China 2002), pp.184-187. (In Chinese).

[3] China National Standardization Management Committee. Specifications of Crane Design (China Standardization Press, China 2008), pp.16-19. (In Chinese).

[4] J. Liu, E.L. Chen and Z.T. He: Journal of Shi Jia Zhuang Railway Institute (Natural Science), Vol. 22 (2009) No. 4, pp.40-42. (In Chinese).

[5] Q. D. Zeng, Q. E. Li: Progress in Civil Engineering, Vol. 32 (2012) No. 9, pp.3077-3080. (In Chinese).
