Servo Control System of NC Modifying Forming Grinding Wheel Based on Cross Coupling Theory

Abstract:

This paper studies the synchronous control strategy which can meet certain dynamic performance and the closed loop robustness to external disturbance in servo system. This servo system has two same PMSMs which are used in a new CNC molding machine for forming grinding wheel. To achieve high-precision of the machine, we designed the hardware construction of the servo system. At the same time, this paper proposes a synchronization control scheme based on cross coupling control algorithms. The performance of the cross-coupled system is theoretically analyzed and simulated. It was proved that this synchronization control scheme has quick response, robustness and small dynamic process synchronization error, which could meet requirements of the high-precision synchronization control.

• Periodical: Advanced Materials Research (Volume 823)
• Pages: 80-83
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.823.80
• Online since: October 2013
• Authors: Hong Lu, Shi Tong Xie, You Wang
• Keywords: Cross Coupling Control, Forming Grinding Wheel, Synchronization Error

References

[1] Jianmin, Zuo, et al. Grinding wheel dressing technology for gear form grinding machine tools., Advanced Technology of Design and Manufacture (ATDM 2011), International Conference on. IET, (2011).

DOI: 10.1049/cp.2011.1042

[2] WANG, Limei, and Yaping TANG. Fuzzy Cross-coupling Compensation Control for Gantry-moving Type CNC Machine Tool [J]., Machine Tool & Hydraulics 3 (2010): 005.

[3] Kim, S., Chu, B., Hong, D., Park, H. K., Park, J. M., & Cho, T. Y. (2003, July). Synchronizing dual-drive gantry of chip mounter with LQR approach. In Advanced Intelligent Mechatronics, 2003. AIM 2003. Proceedings. 2003 IEEE/ASME International Conference on (Vol. 2, pp.838-843.

DOI: 10.1109/aim.2003.1225451

[4] He Zhichao, Chi Zhanduo, Huang Lei, Zheng wanzhe, Ma Zhonghuan. The Method and Evaluation of Testing Double Scre-driven, Machining Center by Laser Interferometer, ACTA METROLOGICA SINICA, 2009, 30(z1).

[5] Teo, C. S., K. K. Tan, and S. Y. Lim. Dynamic geometric compensation for gantry stage using iterative learning control., IEEE Industrial Electronics, IECON 2006-32nd Annual Conference on. IEEE, (2006).

DOI: 10.1109/iecon.2006.347336

[6] Lin, Faa-Jeng, et al. DSP-based cross-coupled synchronous control for dual linear motors via intelligent complementary sliding mode control., Industrial Electronics, IEEE Transactions on 59. 2 (2012): 1061-1073.

DOI: 10.1109/tie.2011.2157286

[7] Jang, M. J., K. C. Lin, and C. L. Chen. Modeling and positioning control of a ball screw driven stage., Networking, Sensing and Control, 2004 IEEE International Conference on. Vol. 2. IEEE, (2004).

DOI: 10.1109/icnsc.2004.1297074
