Research on Single-Stage Grid-Connected Photovoltaic System Based on orCAD/PSpice Analog Behavioral Model

Abstract:

According to mathematical physics model of PV Cell, the simulation model of Si PV array as well as controller model of PV power system is constructed with adoption of orCAD/PSpice10.5 ABM. On this basis, single-stage grid-connected PV system is simulated, and the system which is influenced by intensity of illumination and temperature is analyzed with CAD/PSpice simulation. The simulation results shows that large PV array power system can be simulated to a high approximation degree with CAD/PSpice ABM, and simulation of grid-connected PV power system based on orCAD/PSpice ABM is of practical significance.

• Periodical: Advanced Materials Research (Volume 827)
• Pages: 72-77
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.827.72
• Online since: October 2013
• Authors: Bo Fang, Li Hui Guo
• Keywords: Analogy Behavioral Model (ABM), Improved Constant Voltage Tracking (CVT) Control, orCAD/PSpice, Simulation, Single-Stage Grid-Connected Photovoltaic (PV) System

References

[1] Zhengming ZHAO, Jianzhen LIU, Xiaoying SUN, Liqiang YUAN: Solar Power Photovoltaic Generation and Its Applications, Science Press, Beijing (2005).

[2] Renwang HE, Wanying QIU, Xun WU, etc: Simulation study of new perturbation and observation method in MPPT based on PSIM. Power System Protection and Control, Vol. 40 (7) (2012), pp.56-59.

[3] Xiaolei WANG， Weixing WANG， Jinsheng LU, etc: Modeling of PV array characteristic and application in testing system of PV grid-connected inverter. Power System Protection and Control, Vol. 39 (10) (2011), pp.70-73.

[4] Haifeng FENG, Delin MA, Liangjun XU: Simulation Analysis of Single-Stage Grid Connected Solar Inverter System. Computer Simulation, Vol. 25 (3) (2008), pp.245-250.

[5] Zaiqiang JIAO: Single-Stage Inverter Used in Grid- connected PV Station. Beijing: Institute of Electrical Engineering Chinese Academy of Sciences, (2004).

[6] Zhang-quan WANG, Chao ZHANG, Xiangning HE: Modeling of Photovoltaic-Array Based on Analogy Behavioral Modeling of PSpice Software. Computer Simulation. Vol. 24（8）(2007), pp.225-228.

[7] Zhengmin BAI, Bo FANG, Yuanmin ZHANG: Research on New Type Improved CVT Control of PV based on orCAD/PSpice Analogy Behavioral Model Simulation. Power System Protection and Control, Vol. 39 (21) (2011), pp.126-131.

[8] Soeren Baekhoej Kjaer, John K. Pedersen, Frede Blaabjerg: A Review of Single-Phase Grid Connected Inverters for Photovoltaic Modules. IEEE Transactions on Industry Applications Vol. 41(5) (2005).

DOI: 10.1109/tia.2005.853371

[9] Hongtao NIE: Research and Design of 4KW Charging Station Rooftop Photovoltaic Grid-connected System. Guangzhou: South China University of Technology (2012).

[10] Shicheng. ZHENG: Research on Photovoltaic Generation System and Its Control. Hefei: Hefei University of Technology (2004).
