Experimental Investigations of Nd:YAG Laser Welding of 630 and 321 Stainless Steel and their Effects on Process Parameters

Abstract:

In this paper, the laser welding of the 630 precipitation hardening stainless steel with the 321 austenitic stainless steel was considered. The experiments were carried out with the pulsed Nd: YAG laser under various welding parameters. The effects of power of laser, voltage, duration of pulse, welding speed, beam diameter and frequency, on the weld volume are investigated. The results show that the weld volume increases with voltage and frequency. The weld volume decreases with welding speed and beam diameter. Moreover, the study shows two effects for the duration of pulse. Up to some value of duration of pulse, the weld volume increases. Exceeding, this limit reduces the weld volume. The optical and scanning electron microscopic tests were carried out. The results show that the martensitic structure is produced in the 630 stainless steel side and the austenitic stainless steel is produced in the 321 stainless steel side. The microhardness tests across the samples were carried out. The results show the maximum hardness is for the 630 stainless steel side and the minimum weld hardness is for the 321 stainless steel side. The high voltage may cause hot cracks in the 321 stainless steel side. The effects of gas flow rate on the microstructure were also considered.

• Periodical: Advanced Materials Research (Volumes 83-86)
• Pages: 384-391
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.83-86.384
• Online since: December 2009
• Authors: Seyed Ali Asghar Akbari Mousavi, A.R. Sufizadeh
• Keywords: Laser Beam Welding, Microhardness, Microstructure, Volume of Weld

References

[1] L. Karagiannis, G. Chryssolouris: Nd: YAG laser welding-an Overview. in: Third GR-I international conference on new laser technologies and applications. Proc SPIE 003; 5131: 260- 264.

DOI: 10.1117/12.513646

[2] M. Jokiel, U. Durr, R. Holtz and R. Liebers: Laser welding of dissimilar metals: strategies with pulsed Nd: YAG lasers. In: Lasers in manufacturing 2005. Proc. Third Int. WLT Conf. Lasers in Man., Munich, Germany, June (2005) 631-636.

DOI: 10.2351/1.5060192

[3] J. Wang and H. Zou: J Univ. Sci. & Tech. Beij. Vol. 3, No. 3. (2006), p.213.

[4] J. Nowacki: J. Mat. Proc. Tech. Vol. 14, (2004) 451-463.

[5] S. Kou: Welding Metallurgy, (Wiley& Sons Inc., New York 2003).

[6] C. Lipoid and J. Kotecki, Welding metallurgy and weldability of stainless steels, (John Wiley & Sons, New York 2005).
