Design and Application of Online Calibration System for Automatic Verification Pipeline of Electric Energy Data Acquisition Terminal

Abstract:

In order to improve the detection ability of acquisition terminal, the design scheme of automatic verification pipeline for electric energy data acquisition terminal was proposed. It designed the verification units of automatic verification pipeline and developed the calibration system for dielectric strength test unit, function and error test unit. The testing software to issue test report was developed. The analysis model for calibration data was set up. The process of uncertainty in measurement for auto-measuring result based on GUM algorithm was specified. The results show that the power parameter of automatic verification pipeline can be accurately checked by the calibration system, and consistency of multi-leaving can be ensured. The calibration system is suitable to evaluate the reliability and veracity for the set of automatic verification pipeline. So it provides technical support for speeding up the construction of the electric energy data acquisition system and strong smart grid.

• Periodical: Advanced Materials Research (Volumes 834-836)
• Pages: 1736-1743
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.834-836.1736
• Online since: October 2013
• Authors: Li Jun Dong*
• Keywords: Automatic Verification, Calibration System, Electric Energy Data Acquisition System, Smart Electricity, Uncertainty in Measurement

References

[1] Zhenya Liu. Smart Grid Technology. China Electric Power Press. (2010), in chinese.

[2] Shuyong Chen, Shufang Song, LanXin LI, Summary of smart grid technologies. Power System Technology. (2009)33(8), 1-7, in chinese.

[3] Jiaxin Li, Lijun Qian. Reliability Design and Test of Smart Meter. Power System Technology. (2013)37(1), 28-32, in chinese.

[4] Xiaofeng Wang, Gengqing Li. Power utility information collection system development new trends. Power DSM. (2010)12(5), 59-61, in chinese.

[5] Guishan Long. Research on integrated system of automatic verification and intelligent storage for smart meter. Guizhou Electric Power Technology. (2013)15(7), 31-35, in chinese.

[6] Qifeng Wang, Jian Liu. Simulation Modeling Analysis for AGVS in Smart Meter Automation Test Line. Power System Technology. (2013)37(1), 133-135, in chinese.

[7] Tao Xiao, Fan Zhen. Application Research of Quality Monitoring Technique for Automatic Metrological Verification Pipeline System. Electrical Measurement & Instrumentation, (2013) 50(569), 72-76, in chinese.

[8] Yan Zhang. Research and Application of Intelligent Verification Line System for Smart Meter, Electrical Measurement & Instrumentation, (2009)46(12), 74-77, in chinese.

[9] Q/GDW 575-2010, Technical specification for electric energy data acquisition terminal automatic testing system, in chinese.

[10] GengJun Zhu. Research on the 0. 2s Three-Phase Multi-Functional Power Meter. Measurement & Control Technology. (2011)30(8), 11-13, in chinese.

[11] Jian Ma. A New Method for Watt-hour Meter Calibration. Electrical Measurement & Instrumentation, (2011)48(548), 50-62, in chinese.

[12] American National Standard for Electric Meters-Code or Electricity Meering. ansic12. 1 (1995).

[13] Zhichao Fu. Study on Auto-calibration Technique for Multifuctional Static Watt-Hour Meter. Electrical Measurement & Instrumentation, (2000)37(8), 5-9, in chinese.

[14] Linhong Dan. Development of Intelligent Insulated Resistance and Withstand Voltage test Instrument Based on DSP. PLC technology applications 200 cases. (2009)141-143, in chinese.

[15] Gaohua Liao. Design of Field Test Equipment for Multi-Functional Electrical Energy Meter Low voltage apparatus. (2008)22, 15-19, in chinese.
