Structure and Properties of TiAlLaN Coatings Deposited at Various Ar/N₂ Flow Ratio Using a Mid-Frequency Magnetron Sputtering System

Abstract:

TiAlLaN coatings were deposited on the cemented carbide substrates by mid-frequency magnetron sputtering system. The effects of Ar/N2 flow ratio on the composition, structure, adhesion and hardness followed with elastic modulus and H/E ratio were investigated systematically. Results indicate that all the Ti/Al ratios of the coatings were higher than that of the Ti/Al ratio in the target; however, the Ti/Al ratio increased with the Ar/N2 flow ratio changed. XRD patterns show that the intensity of (111) peak was elevated with the Ar/N2 flow ratio increased. Meanwhile, the peak shifted to lower angles, which implied increases of the lattice parameter. The TiAlLaN coating under the Ar/N2 flow ratio of 3:1 showed the best adhesion, the highest hardness and the lowest H/E ratio which indicated perfect wear resistance.

You might also be interested in these eBooks

Research in Materials and Manufacturing Technologies

View Preview

Info:

Periodical:

Advanced Materials Research (Volumes 834-836)

Pages:

629-633

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.834-836.629

Citation:

Cite this paper

Online since:

October 2013

Authors:

Hao Du, Hai Bo Zhao*, Ji Xiong, Lin Lin Wang, Guang Xian

Keywords:

Adhesion, Ar/N₂ Flow Ratio, Hardness, Structure, TiAlLaN Coatings

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] S.G. Harris, E.D. Doyle and A.C. Vlasveld: Wear. Vol. 256 (2003), p.185.

Google Scholar

[2] A.E. Santana, A. Karimi and V.H. Derflinger: Surf. Coat. Technol. Vol. 177-178 (2004), p.334.

Google Scholar

[3] S.G. Harris, E.D. Doyle and A.C. Vlasveld: Wear. Vol. 254(2003), p.723.

Google Scholar

[4] Chien-Ming Kao, Jyh-Wei Lee and Hsien-Wei Chen: Surf. Coat. Technol. Vol. 205 (2010), p.1438.

Google Scholar

[5] C.W. Zoua, J. Zhanga and W. Xie: Appl. Surf. Sci. Vol. 257 (2011), p.10373.

Google Scholar

[6] E. Ribeiro, A. Malczyk and S. Carvalho: Surf. Coat. Technol. Vol. 151-152 (2002), p.515.

Google Scholar

[7] Chi-Lung Chang, Wei-Chih Chen and Pi-Chuen Tsai: Surf. Coat. Technol. Vol. 202 (2007), p.987.

Google Scholar

[8] Eberhard Pfluger, Achim Schroer and Pierre Voumard: Surf. Coat. Technol. Vol. 115(1999), p.17.

Google Scholar

[9] V.A. Belous, V.V. Vasyliev and V.S. Goltvyanytsya: Surf. Coat. Technol. Vol. 206(2011), p.1720.

Google Scholar

[10] Hao Du, Haibo Zhao and Ji Xiong: Int. J. Refract. Met. Hard Mater. Vol. 37 (2013), p.60.

Google Scholar

[11] Jong-Keuk Park, Jong-Young Cho and Hyeong-Tag Jeon: Vaccum. Vol. 84 (2010), p.483.

Google Scholar

[12] Kee-Sun Lee, Sung-Man Seo and Kee-Ahn Lee: Scripta Mater. Vol. 52 (2005), p.445.

Google Scholar

[13] Hwai-Te Hsueh, Wan-Jui Shen and Ming-Hung Tsai: Surf. Coat. Technol. Vol. 206(2012), p.4106.

Google Scholar

[14] Bor-Yuan Shew, Jow-Lay Huang and Dlng-Fwu Lii: Thin Solid Films Vol. 293 (1997), p.212.

Google Scholar

[15] A.N. Kale, K. Ravindranath and D.C. Kothari: Surf. Coat. Technol. Vol. 145(2001), p.60.

Google Scholar

[16] P.L. Tam, Z.F. Zhou and P.W. Shum: Thin Solid Films. Vol. 516 (2008), p.5725.

Google Scholar

[17] A. Leyland, A. Matthews: Wear. Vol. 246(2000), p.1.

Google Scholar
