Three-Dimensional Nonlinear Finite Element Analysis on the Concrete Face Cock-Fill Dam of TianChi Upper Reservoir

Abstract:

Taking the concrete face cock-fill dam upper reservoir of Tianchi as an example, the stress and deformation characteristics of concrete face rock-fill dam are studied in-depth in this paper. The article builds a fine three-dimensional finite element model of Tianchi upper reservoir by a nonlinear elastic model of the finite element software ADINA. The stress and deformation of the two conditions under completion and storage for the dam are calculated ,which will be analyzed to obtain stress - strain distribution of the dam in two conditions, comparing dam stress and deformation before and after impoundment to get impact of the water pressure on the dam stress and deformation: comparing after impoundment and completion , the dam water level displacement of upstream side from role of horizontal water pressure will increase , the dam upstream offsets to downstream , but the offset is little ; Due to dam is affected by vertical hydrostatic pressure and uplift pressure after impoundment , the dam settlement is slightly less than the completion in storage. KEY WORDS: Tianchi upper reservoir, The concrete face cock-fill dam, Three-dimensional finite element, Nonlinear elastic model, Analysis of stress and deformation

• Periodical: Advanced Materials Research (Volumes 838-841)
• Pages: 1763-1767
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.838-841.1763
• Online since: November 2013
• Authors: Shuang Mei Chang*, Wen She He, Yu Qiang Cheng, Su Min Zhao
• Keywords: Analysisof Stress and Deformation, Concrete Face Cock-Fill Dam, Nonlinear Elastic Model, Three-Dimensional Finite Element, Tianchi Upper Reservoir

References

[1] Cheng Zhanlin, Liu Songtao, et al, 1998. the study on 200mm level high concrete face rock-fill dam by three-dimensional Stress and strain analysis of concrete face rock-fill dam in Shuibuya, Qingjiang [R]. Wuhan : Yangtze River Scientific School. (in Chinese).

DOI: 10.1061/9780784412190.092

[2] Lv Kaige , Kong Xianjing, Lian Zhenying, 2001. 1. The panel and rock-fill interface simulation method study n concrete face Rock-fill dam three -dimensional dynamic calculation [J]. Journal of Gansu Technology University. (in Chinese).

[3] Jiang Pengnian , 1982. the constitutive relation of soil [M] . Beijing : Science Press . (in Chinese).

[4] Wang Mingyuan , He Zhanlin , Lin Shaozhong , 2004. The three -dimensional elastoplastic numerical analysis study on Shuibuya face rock-fill dam [J]. Rock and Soil Mechanics . (in Chinese).

[5] Wang Yuanhan, 2000. Finite element basis and program design [M]. Guangzhou: South China Technology University Press. (in Chinese).

[6] Liu Zude, 1983. several problems about deformation calculation of embankment dam [J]. Journal of Geotechnical Engineering. (in Chinese).

[7] Zhu Xiaoling, 2005. the three -dimensional finite element simulation analysis of concrete face rock-fill dam [J] . Journal of Hydraulic Engineering , (in Chinese).
