Experiment Verification and Model Analysis of Partially-Filled Liquid Tank under Different Liquid Level

Abstract:

In order to analyze the vibration performance of partially-filled liquid tank of ships, this paper takes the integration of measures including numerical simulation with finite element method and experimental verification with LMS vibration test and model analysis system of steel liquid tank under different liquid level conditions to study the fluid-structure interaction phenomenon. With the software of ADINA, the FEM model of the tank is developed and the model analysis which indicates the vibration modes and natural frequencies is completed. The simulation is compared with the experimental results which shows the natural frequency of the structure decreases with the level increases.

• Periodical: Advanced Materials Research (Volume 842)
• Pages: 386-390
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.842.386
• Online since: November 2013
• Authors: Yan Nian Cai*, Bing Nan Liang, Hong Liang Yu, Yu Chao Song
• Keywords: ADINA, Finite Element Method (FEM), Fluid Structure Interaction (FSI), Model Analysis

References

[1] Koh_H M, Kim_J K, Park_J H. Fluid-structure interaction analysis of 3-D rectangular tanks by a variationally coupled BEM-FEM and comparison with test results[J]. Earthquake Engineering & Structural Dynamics, 1998, 27(02): 109-124.

DOI: 10.1002/(sici)1096-9845(199802)27:2<109::aid-eqe714>3.0.co;2-m

[2] Ergin A, Temarel P. Free vibration of a partially liquid-filled and submerged, horizontal cylindrical shell[ J]. Journal of Sound and vibration 2002, 254(5): 951-965.

DOI: 10.1006/jsvi.2001.4139

[3] Suxia Zhang, Xijun Liu, Qifen Jia, et al. Experiment modal analysis on rectangular elastic fluid-filled shell[J]. Journal of Mechanical Strength, 2004, 26(6): 615－619. (In Chinese).

[4] Frandsen J B. Numerical predictions of tuned liquid tank structural systems [J]. Journal of Fluids and Structures 2005, 20(3): 309-329.

DOI: 10.1016/j.jfluidstructs.2004.10.003

[5] Jiaru Qian, Zuozhou Zhao, An Duan, etc. Pseudo-dynamic tests of a 1: 10 model of pr e-stressed concrete containment vessel for CNP1000 nuclear power plant. China Civil Engineering Journal. Vol. 40(2007), pp.7-13. (In Chinese).

[6] Xijun Liu, Stixia Zhang, Guoying Liu, et al. The analysis of gravity waves in a rectangular elastic fluid-shell coupled system[J]. Acta Mechanica Sinica, 2006, 38(1): 106－112. (In Chinese).

[7] Esmailzadeh M, Lakis A A, et al. Three-dimensional Modeling of Curved Structures containing and/or Submerged in Fluid [J]. Finite Elements in Analysis and Design, 2008, 44: 334-345.

DOI: 10.1016/j.finel.2007.11.019

[8] Li Zhang. Model analysis and experiment [M]. Beijing: Tsinghua University Press, 2011. 5(In Chinese).
