Key Technology Discussion on Surveying and Mapping 1:1000 Photogrammetric Digital Topographic Map of Laicheng Industrial Zone in Laiwu City

Abstract:

Taking use of VirtuoZos digital photogrametric workstations of Supresoft Inc., employing full digital aerophotogrammetric mapping method, according to existing aerial photographic image database, at the foundation of basic control survey, we carry out aerial photographic control survey, surveying and mapping with pile point method, digital aerotriangulation and full digital stereocompilation. When taking 1:1000 topographic map obtained by indoor edition to field work for compration, supplement and regulation, we mainly aim at the following purposes: determining the nature and quantity as well as filling vacancy for ground and land features obtained by indoor stereocompilation; positioning for habitation, wall and railing, incompletely surveyed, drop shadow-covered and trees-obstructed ground features, as well as newly-added planimetric features after aerial photogrammetry; especially measuring the solid width of a house to centimeter and making eaves correction after measuring the length of a house when needed; correcting the geomatric positioning relationand of ground features according to their solid shape and fairly drawing them in the map; afterwards, we carry out graphic edition again during indoor work. Only in this way can we guarantee the horizontal and vertical accuracy of large scale photogrammetric mapping.

• Periodical: Advanced Materials Research (Volumes 846-847)
• Pages: 1166-1170
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.846-847.1166
• Online since: November 2013
• Authors: De Bao Wang*, Jun Feng Qu, Xue Ling Fang, Mei Lan Yu
• Keywords: Digital Aerotriangulation, Eaves Correction, Full Digital Stereocompilation, Photographic Control Survey, Pile Point Method of Surveying and Mapping

References

[1] Specifications for Aerophotogrammetric Field Work of 1: 500, 1: 1000 and 1: 2000 Topographic Maps GB/T 7931-2008[S]. Beijing: China Standard Press, 2008, pp.10-17, In Chinese.

[2] Specifications for Aerophotogrammetric Indoor Work of 1: 500, 1: 1000 and 1: 2000 Topographic Maps GB/T 7930-2008[S]. Beijing: China Standard Press, 2008, pp.2-14, In Chinese.

[3] Specifications for Aerotriangulation of Digital Aerophotogrammetry GB/T 23236-2009[S]. Beijing: China Standard Press, 2009, pp.2-6, In Chinese.

[4] CJJ/T73-2010 Specification for satellite positioning and city measurement [S]. Beijing: China Architecture &Building Press, 2010, pp.5-11, In Chinese.

[5] Specifications for the Third and Fourth Order Leveling[S]. Beijing: China Standard Press, 2009, pp.3-15, In Chinese.
