The Temperature-Online-Measuring and Energy-Saving System for Drying Cylinder Based on Network Communication

Abstract:

During the process of drying fabrics by drying cylinder dryer, the over-drying of fabrics leads to a waste of energy. A temperature-online-measuring and energy-saving system for drying cylinder dryer based on network communication was designed in the study. The temperature-measuring and steam-controlling part of the system set in the cylinder dryer communicates with the remote monitoring part using the W5100 network chip through Ethernet which helps to achieve a high-speed and long-distance communication between the two parts. The remote monitoring part of the system is based on Delphi. The real-time temperature of fabrics in each drying cylinder can be displayed on the screen of the remote computer, and the steam supply of drying cylinders can be manually or automatically adjusted according to the mutations of temperature of fabrics by system administrators or the remote computer. The application of this system helps to avoid the The evaporation of water due to over-drying by 5.3%-6.6% and result in a reduction of the waste of energy by about 10%.

• Periodical: Advanced Materials Research (Volumes 846-847)
• Pages: 517-520
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.846-847.517
• Online since: November 2013
• Authors: Chong Qian*, Rong Rong Wang, Wei Wang
• Keywords: Drying Cylinder Dryer, Network Communication, On-Line Technology

References

[1] YANG Chao-yu. Development and Application of Steam Energy Conservation New Technology of Cylinder Dryer, [J]. Progress in Textile Science & Technology, 2011 (6) 41-43.

[2] ZHANG Yang-hui, ZHANG Si-jian, YAN Gang-feng. Design of Control System of Drying Pit Based on PLC, [J]. Modern Machinery, 2007 (4) 9-10.

[3] CAO Yu．Network Communication base on MCU-51 and RTL8019AS, [J]. Application of Electronic Technique, 2006 (29) 21-23.

[4] WlZnet Co. W5100 Porting Guide Ver. 1. 0. WIZnet Co. Korea, (2007).

[5] LIU Guande, YU Xuefei. Design of Medical Instrumentation Network Interface based on SPI Bus and W5100, [J]. Journal of Biomedical Engineering Research, 2008 (3) 202-207.

[6] Feng, J. . A new design of greenhouse remote monitoring system, [J]. Proceedings -International Conference on Electrical and Control Engineering. ICECE (2010) 4904-4907.

[7] YU Chun-xue. Application of W5100 in the Remote Power Quality Monitoring Equipment, [J]. Telecommunications for Electric Power System. 2011 (9) 59-64.
