Fault Location Method Based on Wide-Area Voltage

Abstract:

Backup protection chain tripping caused by flow transferring is one of the most concerned issues in power system. The introduction of wide area backup protection is an effective way to solve the problem. However, in wide area protection system, an effective fault location puts forward a high demand for the location algorithm. This paper presented a method which combined effective mathematical methods with fault location calculation in power system together: firstly used fuzzy clustering analysis method for fast classification of voltage, locked the fault area, and prevented the occurrence of even jump accident at the first time. Then determined the fault location by calculating additional nodal current ratio in the fault area. The method avoids the repeated modification of network structure after fault. It lock the fault to the component quickly and improves the efficiency of fault location greatly.

• Periodical: Advanced Materials Research (Volumes 860-863)
• Pages: 2077-2082
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.860-863.2077
• Online since: December 2013
• Authors: Yan Xu, Lu Man Ying*, Jing Zhi, Ren Qing Feng
• Keywords: Additional Nodal Current Ratio, Fault Location, Fuzzy Clustering, Wide-Area Voltage

References

[1] Zhenya Liu. Accelerate the construction of a strong national grid, promote the sustainable development of China's energy. Electric Power, 2006, 39(9): 1-3.

[2] A.G. Phadke, J.S. Thorp. Expose hidden failures to prevent cascading outages[J]. IEEE Computer Applications in Power, 1996, 9(3): 20-23.

DOI: 10.1109/67.526849

[3] J.C. Tan, P.A. Crossley, P.G. MeLaren, P.F. Gale, Ⅰ. Hall,J. Farrell. Application of a wide area backup protection expert system to prevent cascading outages[J]. IEEE Transactions on Power Delivery, 2002, 17(2): 375-380.

DOI: 10.1109/61.997902

[4] Tan J. C, Crossley P. A, Kirsehen D, et al. An expert system for the back-up protection of a transmission network[J]. IEEE Transactions on Power Delivery, 2000, 15(2): 508-514.

DOI: 10.1109/61.852976

[5] Suonan Jiale , Jiankang Zhang , Hui Liu, et al. A New Method for Fault Components Extraction and FAULT Phases Selection[J]. Automation of Electric Power Systems, 2003, 27(16): 58-61.

[6] Lehtonen M, Hakola Neutral Earthing and Power System Protection[M]. Vaasa, Finland: ABB Transmit Publication. (1996).

[7] Hongwei Du, Yaming Sun, Hongjing Liu, et al. Fault Section Diagnosis and Isolation of Distribution Networks Based on Genetic Algorithm[J]. Power System Technology, 2000, 24(5): 52-55.

[8] Jianxin Cai, Jian Liu, An Uncertainty Reasoning System Based on Trouble Call Information for Locating Faults on Distribution Network[J]. Proceedings of the Csee, 2003, 23(4): 57-61.

[9] Yan Xu, Jinsheng Liu, Yagang Zhang, Location of Faulty Power Network Component Based on Fuzzy Cluster Analysis[J]. Power System Technology, 2010, 34(8): 188-193.

[10] Yan Xu, Jinsheng Liu, Yagang Zhang, Study of application of hierarchical cluster analysis in power net fault location[J]. Power System Protection and Control, 2010, 38(12): 13-18.
