Modeling and Simulation of Compressed Air Energy Storage (CAES) System for Electromechanical Transient Analysis of Power System

Abstract:

CAES system electromotor transient model was established from the view of equipment and the grid interface, based on Power System Analysis Software Package (PSASP). The model was divided into energy storing sub-system model part and generating sub-system model part, and the normal and abnormal dynamic characteristics after CAES connected to the grid were simulated bythis model. The validity of this model was theoretically verified by applying it into example systems and testing.,according to detecting the system responses caused by power system contingency and the sudden change of CAES characteristics. This model provides a basic platform for studying CAES system characteristics, and also provides necessary technical support to the security and stability of power system operation when integrating renewable energy into the grid.

• Periodical: Advanced Materials Research (Volumes 860-863)
• Pages: 2486-2494
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.860-863.2486
• Online since: December 2013
• Authors: Lei He, Tian Xia, Fang Tian, Ning An
• Keywords: Compressed-Air Energy Storage, Electromechanical Transient, Power System

References

[1] XiaoGuangChu, ChengHuiZhang, KeLi, YeFeiJing. A new dynamic and analysis of compressed air energy storage efficiency based on scroll machine. Journal of Electrical Engineering, 2011(7) (In Chinese).

[2] D. lee. Compressed air energy storage power generation. Energy Engineering, 1992(3): 41-43 (In Chinese).

[3] LiYeHu. Gas energy storage power generation technology-compressed air energy storage gas turbine power station, 2006(2): 158-160 (In Chinese).

[4] Hydraulic gas dynamic society of Japan. Hydraulic and pneumatic manual, 425-426.

[5] Cai Maolin. Energy conversion mechanics and power evaluation of compressible fluid in pneumatic actuator systems [C]. Intersociety Energy Conversion Engineering Conference, Tokyo, 2004: 438-443.

DOI: 10.1109/iecec.2002.1392073

[6] Yanagisawa T. Optimum operating pressure ratio for scroll compressor [C]. Proceedings of the International Compressor Engineering Conference, Purdue, 1990: 425-433.

[7] Lemofouet S. A hybrid energy storage system based on compressed air and supercapacitors with maximum efficiency point tracking [J]. IEEE Transactions on Industrial Electronics, 2006, 53(4): 1105-1115.

DOI: 10.1109/tie.2006.878323

[8] Hyun Jin Kim，Jong Min Ahn，Sung Oug Cho, et a1. Numerical simulation on scroll expander compressor unit for CO2 trans-critical cycles [J]. Applied Thermal Enginering, 2008, 28(13): 1654-1661.

DOI: 10.1016/j.applthermaleng.2007.11.002

[9] LianShengLi, Scroll compressor [M]. BeiJing: Machine Industry Press, 1998. (In Chinese).

[10] ROWEN I. Simplified Mathematical Representations of Heavy-duty gas turbines[J]. Journal of Engineering for Power, 1983(105): 865-869.

DOI: 10.1115/1.3227494

[11] FETHI O, DESSAINT L A, Modeling and Simulation of the Electric Part of a Grid Connected Micro Turbine[C]/Power Engineering Society General Meeting. 2004, 2(6): 2212-2219.

DOI: 10.1109/pes.2004.1373274

[12] XingJianZhu. Principle of work and performance of gas turbine[M]. BeiJing: Science Press, 1992. (In Chinese).
